NXP MC56F8367MPYE
NXP MC56F8367MPYE

NXP MC56F8367MPYE

Manufacturer No:

MC56F8367MPYE

Manufacturer:

NXP

Package:

160-LQFP

Description:

512KB 256K x 16 FLASH 56800E 16-Bit Microcontroller 56F8xxx Series MC56F8367 2.5V 160-LQFP

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MC56F8367MPYE information

NXP MC56F8367MPYE technical specifications, attributes, parameters and parts with similar specifications to NXP MC56F8367MPYE.

  • Type
  • Parameter
  • Factory Lead Time
  • 10 Weeks
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 160-LQFP
  • Surface Mount
  • YES
  • Operating Temperature
  • -40°C~125°C TA
  • Packaging
  • Tray
  • Series
  • 56F8xxx
  • Published
  • 1998
  • JESD-609 Code
  • e3
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 3 (168 Hours)
  • Number of Terminations
  • 160
  • ECCN Code
  • 3A991.A.2
  • Terminal Finish
  • Matte Tin (Sn)
  • Additional Feature
  • ALSO REQUIRES 3.3V SUPPLY
  • HTS Code
  • 8542.31.00.01
  • Subcategory
  • Microcontrollers
  • Technology
  • CMOS
  • Terminal Position
  • QUAD
  • Terminal Form
  • GULL WING
  • Peak Reflow Temperature (Cel)
  • 260
  • Supply Voltage
  • 2.5V
  • Terminal Pitch
  • 0.5mm
  • Time@Peak Reflow Temperature-Max (s)
  • 40
  • JESD-30 Code
  • S-PQFP-G160
  • Qualification Status
  • Not Qualified
  • Supply Voltage-Max (Vsup)
  • 2.75V
  • Power Supplies
  • 2.53.3V
  • Supply Voltage-Min (Vsup)
  • 2.25V
  • Oscillator Type
  • External
  • Number of I/O
  • 76
  • Speed
  • 60MHz
  • RAM Size
  • 18K x 16
  • Voltage - Supply (Vcc/Vdd)
  • 2.25V~3.6V
  • uPs/uCs/Peripheral ICs Type
  • DIGITAL SIGNAL PROCESSOR, OTHER
  • Core Processor
  • 56800E
  • Peripherals
  • POR, PWM, Temp Sensor, WDT
  • Clock Frequency
  • 120MHz
  • Program Memory Type
  • FLASH
  • Core Size
  • 16-Bit
  • Program Memory Size
  • 512KB 256K x 16
  • Connectivity
  • CANbus, EBI/EMI, SCI, SPI
  • Bit Size
  • 16
  • Data Converter
  • A/D 16x12b
  • Address Bus Width
  • 24
  • ROM (words)
  • 524288
  • Boundary Scan
  • YES

Download datasheets and manufacturer documentation for NXP MC56F8367MPYE.

Environmental Information:

PCN Packaging:

MC56F8367MPYE Description


MC56F8367MPYE, provided by NXP Semiconductors / Freescale, is a type of digital signal controller optimized for auto and industrial applications. The digital signal processing is combined with microcontroller functionalities on a single chip, with a flexible set of peripherals. Due to on-chip integration and ease of implementation, the development is improved, the component count is lowered, and the system cost is reduced. MC56F8367MPYE digital signal controller is able to simplify designs while promoting compliance with safety regulations.



MC56F8367MPYE Features


  • Available in the LQFP160 package

  • On-chip memory includes high-speed volatile and nonvolatile components

  • Access up to 4 MB of off-chip program and 32 MB of data memory

  • Up to 60 MIPS at 60 MHz execution frequency

  • Chip select logic for glueless interface to ROM and SRAM



MC56F8367MPYE Applications


  • Brushless DC Motor (BLDC) control

  • Permanent Magnet Synchronous Motor (PMSM)


User Guide

PURCHASE
