Harwin M50-3100545R

Manufacturer No:

M50-3100545R

Manufacturer:

Package:

Description:

2 Rows Receptacle Solder Phosphor Bronze Surface Mount Tape & Reel (TR) Gold Liquid Crystal Polymer (LCP) 10 Positions Female Socket

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

M50-3100545R information

Harwin M50-3100545R technical specifications, attributes, parameters and parts with similar specifications to Harwin M50-3100545R.

Type
Parameter

Factory Lead Time
13 Weeks

Contact Material
Phosphor Bronze

Mounting Type
Surface Mount

Contact Shape
Square

Insulation Material
Liquid Crystal Polymer (LCP)

Housing Material
Nylon

Mounting Option 1
LOCKING

Operating Temperature
-40°C~105°C

Packaging
Tape & Reel (TR)

Series
Archer M50

JESD-609 Code
e4

Feature
Pick and Place

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Termination
Solder

ECCN Code
EAR99

Connector Type
Receptacle

Number of Positions
10

Applications
General Purpose, Medical, Telecommunications

Number of Rows
2

Gender
Female

Voltage - Rated
250V

HTS Code
8536.69.40.40

Subcategory
Headers and Edge Type Connectors

Contact Finish - Mating
Gold

MIL Conformance
NO

DIN Conformance
NO

IEC Conformance
NO

Filter Feature
NO

Contact Type
Female Socket

Mixed Contacts
NO

Total Number of Contacts
10

Orientation
Straight

Depth
3.1mm

Insulation Height
0.181 4.60mm

Style
Board to Board or Cable

Number of Positions Loaded
All

Pitch - Mating
0.050 1.27mm

Insulation Color
Black

Number of Conductors
ONE

Reference Standard
UL

Reliability
COMMERCIAL

Row Spacing - Mating
0.050 (1.27mm)

Number Of PCB Rows
2

PCB Contact Pattern
RECTANGULAR

UL Flammability Code
94V-0

Download datasheets and manufacturer documentation for Harwin M50-3100545R.

Datasheets:

harwininc-m503100545r-datasheets-6388.pdf

M50-3100545R Overview

Currently, it is packaged in Receptacle.Mounting type Surface Mount is assigned to the device.Packaging the product involves using a Tape & Reel (TR) case.Among the products in the Archer M50 Series, it is one of the most popular.The device could be used for General Purpose, Medical, Telecommunications.A number of benefits can be derived from the Pick and Place feature of this application.-40°C~105°C Operating Temperature is used by the device.

M50-3100545R Features

Archer M50 series

M50-3100545R Applications

There are a lot of Harwin Inc.
M50-3100545R Rectangular Connectors applications.

Embedded systems
Datacom
Communication
Medical technology
Military Technology
Measuring & Control Technology
Instrumentation
Automotive Electronics
Telecommunications
Data Technology
