ONSEMI LV8104V-TLM-H

Manufacturer No:

LV8104V-TLM-H

Manufacturer:

ONSEMI

Package:

44-LSSOP (0.220, 5.60mm Width)

Description:

5.6mm mm Motor Drivers 44 24V V 5V V Motion Control Electronics

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

LV8104V-TLM-H information

ONSEMI LV8104V-TLM-H technical specifications, attributes, parameters and parts with similar specifications to ONSEMI LV8104V-TLM-H.

Type
Parameter

Lifecycle Status
ACTIVE (Last Updated: 1 week ago)

Factory Lead Time
14 Weeks

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
44-LSSOP (0.220, 5.60mm Width)

Number of Pins
44

Operating Temperature
-20°C~80°C TA

Packaging
Tape & Reel (TR)

Published
2010

JESD-609 Code
e6

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
44

Terminal Finish
Tin/Bismuth (Sn/Bi)

Applications
General Purpose

Subcategory
Motion Control Electronics

Technology
Bi-CMOS

Voltage - Supply
16V~28V

Terminal Position
DUAL

Terminal Form
GULL WING

Supply Voltage
24V

Terminal Pitch
0.65mm

Base Part Number
LV8104

Number of Outputs
1

Output Voltage
5V

Supply Voltage-Max (Vsup)
28V

Power Supplies
24V

Interface
Parallel

Analog IC - Other Type
BRUSHLESS DC MOTOR CONTROLLER

Nominal Supply Current
15mA

Output Configuration
Pre-Driver - Half Bridge (3)

Output Current
15mA

Halogen Free
Halogen Free

Supply Current-Max (Isup)
8.2mA

Motor Type - AC, DC
Brushless DC (BLDC)

Width
5.6mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free
