ADI LTC4090EDJC#PBF
ADI LTC4090EDJC#PBF

ADI LTC4090EDJC#PBF

Manufacturer No:

LTC4090EDJC#PBF

Manufacturer:

ADI

Package:

22-WFDFN Exposed Pad

Description:

5V -40°C~85°C TA 1 Channel DUAL Battery Management ICs 5V LTC4090 22 Pins Lithium Ion/Polymer 22-WFDFN Exposed Pad

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

LTC4090EDJC#PBF information

ADI LTC4090EDJC#PBF technical specifications, attributes, parameters and parts with similar specifications to ADI LTC4090EDJC#PBF.

  • Type
  • Parameter
  • Lifecycle Status
  • PRODUCTION (Last Updated: 1 week ago)
  • Factory Lead Time
  • 8 Weeks
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 22-WFDFN Exposed Pad
  • Surface Mount
  • YES
  • Number of Pins
  • 22
  • Operating Temperature
  • -40°C~85°C TA
  • Packaging
  • Tube
  • Published
  • 2005
  • JESD-609 Code
  • e3
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 22
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Matte Tin (Sn)
  • Technology
  • CMOS
  • Terminal Position
  • DUAL
  • Terminal Form
  • NO LEAD
  • Peak Reflow Temperature (Cel)
  • 260
  • Supply Voltage
  • 5V
  • Terminal Pitch
  • 0.5mm
  • Frequency
  • 2.7MHz
  • Time@Peak Reflow Temperature-Max (s)
  • 30
  • Base Part Number
  • LTC4090
  • Qualification Status
  • Not Qualified
  • Power Supplies
  • 5V
  • Number of Channels
  • 1
  • Interface
  • USB
  • Max Supply Voltage
  • 5.5V
  • Min Supply Voltage
  • 4.35V
  • Analog IC - Other Type
  • POWER SUPPLY SUPPORT CIRCUIT
  • Number of Ports
  • 1
  • Adjustable Threshold
  • YES
  • Min Input Voltage
  • 6V
  • Max Input Voltage
  • 60V
  • Nominal Input Voltage
  • 5.5V
  • Fault Protection
  • Over Current, Over Temperature
  • Battery Chemistry
  • Lithium Ion/Polymer
  • Height
  • 750?m
  • Length
  • 6mm
  • Width
  • 3mm
  • REACH SVHC
  • No SVHC
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for ADI LTC4090EDJC#PBF.

Datasheets:

ConflictMineralStatement:

LTC4090EDJC#PBF Overview


This package corresponds to 22-WFDFN Exposed Pad. POWER SUPPLY SUPPORT CIRCUIT is the analog IC used by this power management IC. It is possible to access 1 channels. The smart tools battery has 22 pins in total. A Tube case holds it. It is recommended that this electric part's minimum supply voltage not be less than 4.35V volts. There is a electronic part mounted in the way of Surface Mount. 5.5V voltage greater than 5.5V volts should be supplied to this electronic battery. In addition to Power Management functions, it can deliver other functions as well. When a electronic part is operated at -40°C~85°C TA, its performance will be optimal. This electronic part includes a Lithium Ion/Polymer chemistry battery. The manage ICs is powered by an electric current of 5V volts. All times this battery protection IC should be set to 5V. There is a LTC4090 family at the core of it. The system battery input voltage can be powered under 60V. There is 6V problem operating the manage IC below 6V voltage.
