ADI LTC3212EDDB#TRPBF

Manufacturer No:

LTC3212EDDB#TRPBF

Manufacturer:

ADI

Package:

12-WFDFN Exposed Pad

Description:

0.45mm PMIC LTC3212 900kHz 3.6V 12-WFDFN Exposed Pad

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

LTC3212EDDB#TRPBF information

ADI LTC3212EDDB#TRPBF technical specifications, attributes, parameters and parts with similar specifications to ADI LTC3212EDDB#TRPBF.

Type
Parameter

Factory Lead Time
8 Weeks

Mounting Type
Surface Mount

Package / Case
12-WFDFN Exposed Pad

Surface Mount
YES

Operating Temperature
-40°C~85°C TA

Packaging
Tape & Reel (TR)

Published
2007

JESD-609 Code
e3

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
12

ECCN Code
EAR99

Type
DC DC Regulator

Terminal Finish
Matte Tin (Sn)

Applications
Backlight

Subcategory
Display Drivers

Technology
CMOS

Terminal Position
DUAL

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Supply Voltage
3.6V

Terminal Pitch
0.45mm

Frequency
900kHz

Base Part Number
LTC3212

Pin Count
12

JESD-30 Code
R-PDSO-N12

Number of Outputs
3

Qualification Status
Not Qualified

Voltage - Output
5.1V

Topology
Switched Capacitor (Charge Pump)

Current - Output / Channel
25mA

Internal Switch(s)
Yes

Number of Segments
3

Voltage - Supply (Max)
5.5V

Voltage - Supply (Min)
2.7V

Multiplexed Display Capability
NO

Data Input Mode
PARALLEL

Height Seated (Max)
0.8mm

Width
2mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for ADI LTC3212EDDB#TRPBF.

Datasheets:

lineartechnologyanalogdevices-ltc3212eddbtrmpbf-datasheets-0678.pdf

LTC3212EDDB#TRPBF Overview

Its 12-WFDFN Exposed Pad package is used to save board space. There are 3 outputs used for the design of this LED drivers.It adopts the way of Surface Mount for mounting.It emergys as a DC DC Regulator with high efficiency and reliable performance.It is able to work normally at the operating temperature of -40°C~85°C TA.It provides considerable benefits for Backlight.It operates based on the frequency of 900kHz.12 terminations are designed for its operation.If the voltage supply is less than 2.7V, undetermined failures will occur.There are 3 segments.This LED driver can be found under the base part number LTC3212.The voltage at the output terminal is 5.1V.It is equipped with 12 pin count.It is optimized for offering a maximum value of supply voltage of 5.5V.It is also classified into Display Drivers according to its characteristics.
