ADI LT6654AMPS6-4.096#TRMPBF

Manufacturer No:

LT6654AMPS6-4.096#TRMPBF

Manufacturer:

ADI

Package:

SOT-23-6 Thin, TSOT-23-6

Description:

-55°C~125°C TA Fixed PMIC LT6654 1 Channel SOT-23-6 Thin, TSOT-23-6

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

LT6654AMPS6-4.096#TRMPBF information

ADI LT6654AMPS6-4.096#TRMPBF technical specifications, attributes, parameters and parts with similar specifications to ADI LT6654AMPS6-4.096#TRMPBF.

Type
Parameter

Lifecycle Status
PRODUCTION (Last Updated: 2 weeks ago)

Factory Lead Time
8 Weeks

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
SOT-23-6 Thin, TSOT-23-6

Number of Pins
6

Operating Temperature
-55°C~125°C TA

Packaging
Tape & Reel (TR)

Tolerance
±0.05%

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Temperature Coefficient
10ppm/°C

Base Part Number
LT6654

Output Voltage
4.096V

Output Type
Fixed

Number of Channels
1

Operating Supply Current
600?A

Voltage - Input
4.596V~36V

Current - Output
10mA

Quiescent Current
350?A

Reference Type
Series

Min Output Voltage
4.096V

Noise - 0.1Hz to 10Hz
2ppmp-p

Noise - 10Hz to 10kHz
2ppmrms

Lead Free
Lead Free

Download datasheets and manufacturer documentation for ADI LT6654AMPS6-4.096#TRMPBF.

Datasheets:

lineartechnologyanalogdevices-lt6654bhs64096trmpbf-datasheets-7127.pdf

lineartechnologyanalogdevices-lt6654bhs64096trmpbf-datasheets-7131.pdf

analogdevices-lt6654amps64096trmpbf-datasheets-1104.pdf

analogdevices-lt6654amps64096trmpbf-datasheets-1105.pdf

ConflictMineralStatement:

analogdeviceslineartechnology-lt5400bhms8e8trpbf-conflictmineralstatement-8771.pdf

LT6654AMPS6-4.096#TRMPBF Overview

The reference voltage makes use of a handy SOT-23-6 Thin, TSOT-23-6 package.This program utilizes the handy Series package.The reference voltage is enclosed in the Tape & Reel (TR) external packaging.±0.05% tolerance for precise voltage reference.It outputs 4.096V voltage according to the test statistics.It can handle Fixed output (s).6 pins are settled in the voltage reference ic.Surface Mount is available for demanding PCB design.Qualified to work within -55°C~125°C TA.Other relevant parts can be found by searching "LT6654".It is suitable for 10mA input applications.It is appropriate for Surface Mount applications.There are 1 channels for high-quality communication.The lowest voltage output from the voltage reference ic is 4.096V lower than 4.096V.Commonly, the voltage reference ic can supply a 4.596V~36V voltage input.The voltage reference circuit uses 350?A when it is idle.It runs on 600?A supply current.

LT6654AMPS6-4.096#TRMPBF Features

±0.05% Tolerance
Channel Number: 1

LT6654AMPS6-4.096#TRMPBF Applications

There are a lot of Linear Technology/Analog Devices
LT6654AMPS6-4.096#TRMPBF Voltage Reference applications.

Portable, battery-powered equipment
Cellular phones, notebook computers, PDAs, GPSs, and DMMs
Computer workstations
Suitable for use with a wide range of video RAMDACs
Smart industrial transmitters
PCMCIA cards
Automotive
3 V/5 V, 8-bit to 12-bit data converters
Precision data acquisition systems
High resolution converters
