ADI LT1079SW#PBF

Manufacturer No:

LT1079SW#PBF

Manufacturer:

ADI

Package:

16-SOIC (0.295, 7.50mm Width)

Description:

7nA 112 dB Instrumentational OP Amps 0.011μA 2.2V~30V ±1.1V~15V LT1079 16 Pins 16-SOIC (0.295, 7.50mm Width)

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

LT1079SW#PBF information

ADI LT1079SW#PBF technical specifications, attributes, parameters and parts with similar specifications to ADI LT1079SW#PBF.

Type
Parameter

Factory Lead Time
8 Weeks

Mounting Type
Surface Mount

Package / Case
16-SOIC (0.295, 7.50mm Width)

Surface Mount
YES

Operating Temperature
0°C~70°C

Packaging
Tube

Published
2001

JESD-609 Code
e3

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
16

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn)

Subcategory
Operational Amplifier

Technology
BIPOLAR

Terminal Position
DUAL

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
260

Number of Functions
4

Supply Voltage
15V

Terminal Pitch
1.27mm

Time@Peak Reflow Temperature-Max (s)
30

Base Part Number
LT1079

Pin Count
16

Qualification Status
Not Qualified

Power Supplies
5/+-15V

Number of Circuits
4

Current - Supply
47μA

Slew Rate
0.1V/μs

Architecture
VOLTAGE-FEEDBACK

Amplifier Type
General Purpose

Common Mode Rejection Ratio
112 dB

Current - Input Bias
7nA

Voltage - Supply, Single/Dual (±)
2.2V~30V ±1.1V~15V

Gain Bandwidth Product
200kHz

Neg Supply Voltage-Nom (Vsup)
-15V

Unity Gain BW-Nom
200 kHz

Average Bias Current-Max (IIB)
0.011μA

Low-Offset
YES

Frequency Compensation
YES

Supply Voltage Limit-Max
22V

Voltage - Input Offset
80μV

Micropower
YES

Bias Current-Max (IIB) @25C
0.01μA

Neg Supply Voltage-Max (Vsup)
-22V

Voltage Gain-Min
80000

Length
10.3mm

Download datasheets and manufacturer documentation for ADI LT1079SW#PBF.

Datasheets:

lineartechnologyanalogdevices-lt1078cn8pbf-datasheets-8326.pdf

LT1079SW#PBF Overview

In order to protect the op amps, a 16-SOIC (0.295, 7.50mm Width) case is used. There are two types of operational amplifiers in this circuit. In the case of Tube cases, linear amplifier will be delivered. In recent months, the number of terminations has approached 16. It consists of a total of 16 pins in total. It would be helpful if you could remember that this op amp ic should be powered by an 15V battery. A type of Operational Amplifier buffer op amp is what this device is specifically, to be more precise. This electronic component is recommended to be mounted using the mounting type Surface Mount. It is recommended that this op amp ic be operated at a temperature no higher than 0°C~70°C for optimal performance. In total, there are 4 circuits on this buffer amplifier. This electronic part is recommended to be used with an 47μA supply for best performance. A minimum voltage gain of 80000 is the minimum voltage gain that this instrumentation amplifier is capable of producing.
