Manufacturer No:

LS1021ASE7HNB

Manufacturer:

NXP

Package:

525-FBGA, FCBGA

Description:

0.8mm ARM® Cortex®-A7 Microprocessor QorIQ® Layerscape Series 1V 525-FBGA, FCBGA

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

LS1021ASE7HNB information

NXP LS1021ASE7HNB technical specifications, attributes, parameters and parts with similar specifications to NXP LS1021ASE7HNB.

  • Type
  • Parameter
  • Factory Lead Time
  • 18 Weeks
  • Package / Case
  • 525-FBGA, FCBGA
  • Surface Mount
  • YES
  • Operating Temperature
  • 0°C~105°C
  • Packaging
  • Tray
  • Series
  • QorIQ® Layerscape
  • Published
  • 2002
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 3 (168 Hours)
  • Number of Terminations
  • 525
  • ECCN Code
  • 5A002.A.1
  • HTS Code
  • 8542.31.00.01
  • Technology
  • CMOS
  • Terminal Position
  • BOTTOM
  • Terminal Form
  • BALL
  • Peak Reflow Temperature (Cel)
  • NOT SPECIFIED
  • Supply Voltage
  • 1V
  • Terminal Pitch
  • 0.8mm
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • JESD-30 Code
  • S-PBGA-B525
  • Supply Voltage-Max (Vsup)
  • 1.03V
  • Supply Voltage-Min (Vsup)
  • 0.97V
  • Speed
  • 800MHz
  • uPs/uCs/Peripheral ICs Type
  • MICROPROCESSOR CIRCUIT
  • Ethernet
  • GbE (3)
  • Number of Cores/Bus Width
  • 2 Core 32-Bit
  • RAM Controllers
  • DDR3L, DDR4
  • USB
  • USB 3.0 (1) + PHY
  • Security Features
  • Secure Boot, TrustZone®
  • Display & Interface Controllers
  • 2D-ACE
  • SATA
  • SATA 6Gbps (1)
  • Length
  • 19mm
  • Height Seated (Max)
  • 2.07mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for NXP LS1021ASE7HNB.

Datasheets:

Environmental Information:

PCN Design/Specification:

LS1021ASE7HNB Overview


The embedded microprocessor ships overseas conveniently packed in 525-FBGA, FCBGA. A high level of reliability is provided by using an advanced packaging method Tray. In the CPU, there are 2 Core 32-Bit cores and 2 Core 32-Bit bus width. It is important to understand the operating temperature around 0°C~105°C. QorIQ® Layerscape is its series number. Core-wise, this CPU has a ARM® Cortex®-A7 processor. It has DDR3L, DDR4 RAM controllers. There is MICROPROCESSOR CIRCUIT MICROPROCESSOR CIRCUIT in the uPs, uCs, or peripheral ICs categories. A total of 525 terminations have been recorded. Turn on the cpu microprocessor and let it run with a 1V voltage supply. With a maximum supply current of 1.03V, it has a maximum power consumption.
