LPC812M101JTB16X Information

NXP LPC812M101JTB16X technical specifications, attributes, parameters and parts with similar specifications to NXP LPC812M101JTB16X.

  • Type
  • Parameter
  • Factory Lead Time
  • 12 Weeks
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 16-XFDFN
  • Surface Mount
  • YES
  • Number of I/Os
  • 14
  • ROM(word)
  • 16384
  • Operating Temperature
  • -40°C~105°C TA
  • Packaging
  • Tape & Reel (TR)
  • Series
  • LPC81xM
  • Published
  • 2010
  • Type
  • Parameter
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 16
  • Terminal Position
  • DUAL
  • Terminal Form
  • NO LEAD
  • Peak Reflow Temperature (Cel)
  • NOT SPECIFIED
  • Supply Voltage
  • 3.3V
  • Terminal Pitch
  • 0.4mm
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Base Part Number
  • LPC812M101

Download datasheets and manufacturer documentation for NXP LPC812M101JTB16X.

Datasheets:

Environmental Information:

LPC812M101JTB16X Description


The LPC81xM is a low-cost 32-bit MCU series with an ARM Cortex-M0+ processor that operates at CPU frequencies of up to 30 MHz. Up to 16 kB of flash memory and 4 kB of SRAM are supported by the LPC81xM.

The LPC81xM's peripheral complement consists of a CRC engine, an input pattern match engine, an I2C-bus interface, up to three USARTs, up to two SPI interfaces, one comparator, a function-configurable I/O port through a switch matrix, one multi-rate timer, a self-wake-up timer, and a state-configurable timer.



LPC812M101JTB16X Features


  • Unique device serial number for identification.

  • Single power supply.

  • Operating temperature range -40 °C to 105 °C except for the DIP8 package, which is

  • available for a temperature range of -40 °C to 85 °C.

  • Available as DIP8, TSSOP16, SO20, TSSOP20, and XSON16 package.

  • Boot loader.

  • USART drivers.

  • I2C drivers.

  • Power profiles.

  • Flash In-Application Programming (IAP) and In-System Programming (ISP).



LPC812M101JTB16X Applications


  • 8/16-bit applications

  • Lighting

  • Consumer

  • Motor control

  • Climate control

  • Fire and security applications
