NXP LPC2364FBD100
NXP LPC2364FBD100

NXP LPC2364FBD100

Manufacturer No:

LPC2364FBD100

Manufacturer:

NXP

Package:

LQFP

Description:

Microcontroller 100 Pin 72MHz LQFP

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

LPC2364FBD100 information

NXP LPC2364FBD100 technical specifications, attributes, parameters and parts with similar specifications to NXP LPC2364FBD100.

  • Type
  • Parameter
  • Mount
  • Surface Mount
  • Package / Case
  • LQFP
  • Number of Pins
  • 100
  • Termination
  • SMD/SMT
  • Max Operating Temperature
  • 85°C
  • Min Operating Temperature
  • -40°C
  • Frequency
  • 72MHz
  • Interface
  • CAN, I2C, I2S, SPI, UART, USB
  • Max Supply Voltage
  • 3.6V
  • Min Supply Voltage
  • 3V
  • Memory Size
  • 128kB
  • Number of I/O
  • 70
  • RAM Size
  • 8kB
  • Memory Type
  • FLASH
  • Peripherals
  • DMA, PWM
  • Frequency (Max)
  • 72MHz
  • Number of Timers/Counters
  • 4
  • Density
  • 1 Mb
  • Core Architecture
  • ARM
  • Number of ADC Channels
  • 6
  • Number of I2C Channels
  • 3
  • Number of Ethernet Channels
  • 1
  • Height
  • 1.45mm
  • Length
  • 14.1mm
  • REACH SVHC
  • No SVHC
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for NXP LPC2364FBD100.

RohsStatement:

LPC2364FBD100  Description

The LPC2364/65/66/67/68 microcontrollers are based on a 16-bit/32-bit ARM7TDMI-S CPU with real-time emulation that combines the microcontroller with up to 512 kB of embedded high-speed flash memory. A 128-bit wide memory interface and a unique accelerator architecture enable 32-bit code execution at the maximum clock rate. For critical performance in interrupt service routines and DSP algorithms, this increases performance up to 30 % over Thumb mode. For critical code size applications, the alternative 16-bit Thumb mode reduces code by more than 30 % with a minimal performance penalty.



LPC2364FBD100  Features

ARM7TDMI-S processor, running at up to 72 MHz

Up to 512 kB on-chip flash program memory with In-System Programming (ISP) and

In-Application Programming (IAP) capabilities. Flash program memory is on the ARM

local bus for high-performance CPU access.

8 kB/32 kB of SRAM on the ARM local bus for high-performance CPU access.

16 kB SRAM for Ethernet interface. Can also be used as a general-purpose SRAM.

8 kB SRAM for general purpose DMA use is also accessible by USB.

Dual Advanced High-performance Bus (AHB) system that provides for simultaneous

Ethernet DMA, USB DMA, and program execution from on-chip flash with no

contention between those functions. A bus bridge allows the Ethernet DMA to access

the other AHB subsystem.

Advanced Vectored Interrupt Controller (VIC), supporting up to 32 vectored interrupts.

General Purpose DMA controller (GPDMA) on AHB that can be used with the SSP

serial interfaces, the I2S port, and the Secure Digital/MultiMediaCard (SD/MMC) card

port, as well as for memory-to-memory transfers.
