TI LOG100JP

Manufacturer No:

LOG100JP

Manufacturer:

Package:

14-CDIP (0.300, 7.62mm)

Description:

5mA per Channel 1pA Instrumentational OP Amps ±12V~18V LOG100 14 Pins 14-CDIP (0.300, 7.62mm)

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

LOG100JP information

TI LOG100JP technical specifications, attributes, parameters and parts with similar specifications to TI LOG100JP.

Type
Parameter

Mount
Through Hole

Mounting Type
Through Hole

Package / Case
14-CDIP (0.300, 7.62mm)

Operating Temperature
0°C~70°C

Packaging
Tube

Pbfree Code
no

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
14

ECCN Code
EAR99

Subcategory
Analog Computational Functions

Max Power Dissipation
600mW

Terminal Position
DUAL

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Number of Functions
1

Supply Voltage
15V

Terminal Pitch
2.54mm

Reach Compliance Code
not_compliant

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Base Part Number
LOG100

Pin Count
14

Qualification Status
Not Qualified

Number of Circuits
1

Analog IC - Other Type
LOG OR ANTILOG AMPLIFIER

Power Dissipation
600mW

Quiescent Current
7mA

Amplifier Type
Logarithmic and Log Ratio

Current - Input Bias
1pA

Voltage - Supply, Single/Dual (±)
±12V~18V

Output Current per Channel
5mA

Input Offset Voltage (Vos)
700μV

Bandwidth
0.045MHz

Supply Current-Max (Isup)
9mA

Neg Supply Voltage-Nom (Vsup)
-15V

-3db Bandwidth
45kHz

Length
20.065mm

Height Seated (Max)
5.46mm

RoHS Status
RoHS Compliant

Lead Free
Contains Lead

Download datasheets and manufacturer documentation for TI LOG100JP.

Datasheets:

texasinstruments-log100jp-datasheets-7431.pdf

LOG100JP Overview

In order to protect the op amps, a 14-CDIP (0.300, 7.62mm) case is used. There are two types of operational amplifiers in this circuit. In the case of Tube cases, linear amplifier will be delivered. In recent months, the number of terminations has approached 14. It consists of a total of 14 pins in total. It would be helpful if you could remember that this op amp ic should be powered by an 15V battery. A type of Analog Computational Functions buffer op amp is what this device is specifically, to be more precise. In terms of input offset voltage, operational amplifier rates 700μV. This electronic component is recommended to be mounted using the mounting type Through Hole. It is recommended that this op amp ic be operated at a temperature no higher than 0°C~70°C for optimal performance. In order for this instrumentation amplifier to operate, the supply current needs to be between 7mA and 10 . In total, there are 1 circuits on this buffer amplifier. There is an 7mA quiescent current in linear amplifier. Besides the analog ICs used in this instrumentation amplifier, there is also another type of analog IC called LOG OR ANTILOG AMPLIFIER IC.

LOG100JP Features

14 Pins
supply voltage of 15V

LOG100JP Applications

There are a lot of Texas Instruments
LOG100JP Instrumentational OP Amps applications.

Differentiator circuits
Logarithmic operation circuits
Exponential operation circuits
Multiplication circuits
Division circuits
Precision measurement
Power control
Information processing
Weak signal detection
Signal amplification
