TI LM48820TM/NOPB

Manufacturer No:

LM48820TM/NOPB

Manufacturer:

Package:

14-WFBGA, DSBGA

Description:

4.7mA mA 22 kHz kHz 95mW W Audio Amplifiers 675?m mm 0m mm 5V V 14 pins 14-WFBGA, DSBGA

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

LM48820TM/NOPB information

TI LM48820TM/NOPB technical specifications, attributes, parameters and parts with similar specifications to TI LM48820TM/NOPB.

Type
Parameter

Lifecycle Status
ACTIVE (Last Updated: 2 days ago)

Factory Lead Time
6 Weeks

Contact Plating
Copper, Silver, Tin

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
14-WFBGA, DSBGA

Number of Pins
14

Operating Temperature
-40°C~85°C TA

Packaging
Tape & Reel (TR)

Series
Boomer®

JESD-609 Code
e1

Feature
Depop, Shutdown, Thermal Protection

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
14

Termination
SMD/SMT

ECCN Code
EAR99

Type
Class AB

Terminal Finish
Tin/Silver/Copper (Sn/Ag/Cu)

Additional Feature
SNR IS 100DB

Subcategory
Audio/Video Amplifiers

Voltage - Supply
1.6V~4.5V

Terminal Position
BOTTOM

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Terminal Pitch
0.4mm

Base Part Number
LM48820

Pin Count
14

Output Type
Headphones, 2-Channel (Stereo)

Supply Voltage-Max (Vsup)
5V

Power Supplies
3V

Supply Voltage-Min (Vsup)
1.6V

Number of Channels
2

Nominal Supply Current
4.7mA

Output Power
95mW

Supply Type
Single

Bandwidth
22 kHz

Voltage Gain
3.52dB

Power Supply Rejection Ratio (PSRR)
80dB

Max Output Power
95mW

Max Output Power x Channels @ Load
95mW x 2 @ 16 ?

Load Impedance
2kOhm

Height
675?m

Length
0m

Width
0m

Thickness
420?m
