TI LM4780TA/NOPB
Manufacturer No:
LM4780TA/NOPB
Manufacturer:
Package:
TO-220-27 Formed Leads
Description:
110mA mA 8MHz kHz 60W W Audio Amplifiers 15.6972mm mm 4.4958mm mm 125W W 27 pins TO-220-27 Formed Leads
Quantity:
Delivery:
Payment:
In Stock :Available
Price not displayed? Please send an RFQ, and we will respond immediately.
LM4780TA/NOPB information
TI LM4780TA/NOPB technical specifications, attributes, parameters and parts with similar specifications to TI LM4780TA/NOPB.
- Type
- Parameter
- Mount
- Through Hole
- Mounting Type
- Through Hole
- Package / Case
- TO-220-27 Formed Leads
- Number of Pins
- 27
- Weight
- 9.071847g
- Operating Temperature
- -20°C~85°C TA
- Packaging
- Tube
- Series
- Overture?
- JESD-609 Code
- e3
- Feature
- Depop, Mute, Short-Circuit and Thermal Protection
- Pbfree Code
- no
- Part Status
- Obsolete
- Moisture Sensitivity Level (MSL)
- 1 (Unlimited)
- Number of Terminations
- 27
- ECCN Code
- EAR99
- Type
- Class AB
- Terminal Finish
- Matte Tin (Sn)
- Subcategory
- Audio/Video Amplifiers
- Max Power Dissipation
- 125W
- Voltage - Supply
- 20V~84V ±10V~42V
- Terminal Position
- ZIG-ZAG
- Number of Functions
- 1
- Base Part Number
- LM4780
- Output Type
- 2-Channel (Stereo)
- Number of Channels
- 2
- Nominal Supply Current
- 110mA
- Power Dissipation
- 125W
- Quiescent Current
- 110mA
- Output Power
- 60W
- Slew Rate
- 19 V/?s
- Common Mode Rejection Ratio
- 85 dB
- Supply Type
- Dual, Single
- Input Offset Voltage (Vos)
- 10mV
- Bandwidth
- 8MHz
- Gain Bandwidth Product
- 8MHz
- Voltage Gain
- 115dB
- Power Supply Rejection Ratio (PSRR)
- 120dB
- Gain
- 34 dB
- Max Dual Supply Voltage
- 42V
- Max Output Power
- 60W
- Min Dual Supply Voltage
- 10V
- Dual Supply Voltage
- 28V
- Input Bias Current
- 1?A
- Max Output Power x Channels @ Load
- 60W x 2 @ 8 ?
- Load Impedance
- 4Ohm
- Height
- 15.6972mm
- Length
- 29.21mm
