LM3503ITL-35/NOPB Information

TI LM3503ITL-35/NOPB technical specifications, attributes, parameters and parts with similar specifications to TI LM3503ITL-35/NOPB.

Type
Parameter

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
10-WFBGA, DSBGA

Number of Pins
10

Operating Temperature
-40°C~85°C TA

Packaging
Tape & Reel (TR)

JESD-609 Code
e1

Pbfree Code
no

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Type
Parameter

Number of Terminations
10

ECCN Code
EAR99

Type
DC DC Regulator

Terminal Finish
Tin/Silver/Copper (Sn/Ag/Cu)

Applications
Backlight

Subcategory
Display Drivers

Terminal Position
BOTTOM

Terminal Form
BALL

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Download datasheets and manufacturer documentation for TI LM3503ITL-35/NOPB.

Datasheets:

texasinstruments-lm3503itlx16nopb-datasheets-9938.pdf

PCN Obsolescence/ EOL:

texasinstruments-lm3432bsqenopb-pcnobsolescenceeol-5111.pdf

LM3503ITL-35/NOPB Overview

In order to save board space, the led driver uses the 10-WFBGA, DSBGA package. For the design of this LED driver, 2 outputs are used.The mounting method is Surface Mount.As a DC DC Regulator, it has high efficiency and reliability.The led light driver operates normally at -40°C~85°C TA. The benefits it provides to Backlight are considerable.The terminations 10 are designed for its operation.To form its configuration, 10 pins are used.A voltage supply less than 2.5V will cause undetermined failures.The segment count is 2.Surface Mount is mounted in the way.There is a base part number LM3503 for this LED driver.A maximum supply voltage of 5.5V is acceptable.There is 35V voltage output from it.The device has 10 pins.The Display Drivers is also assigned based on its characteristics.It achieves maximum efficiency with a minimal voltage supply of 2.5V.If the maximum supply current is less than 3mA, the device is capable of providing high efficiency.A load can be supplied with 1.05A current.It is capable of fulfilling its full functionality when the switching frequency remains at 1MHz.In the absence of external factors, there is 1.9mA consumption of current.
