TDK LEDC10-12-R48

Manufacturer No:

LEDC10-12-R48

Manufacturer:

TDK

Package:

Description:

PMIC 11 Pin

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

LEDC10-12-R48 information

TDK LEDC10-12-R48 technical specifications, attributes, parameters and parts with similar specifications to TDK LEDC10-12-R48.

Type
Parameter

Mount
Through Hole

Number of Pins
11

Weight
6.350293 g

Efficiency (%)
87 %

Max Operating Temperature
85 °C

Min Operating Temperature
-40 °C

Max Power Dissipation
10 W

Number of Outputs
1

Output Voltage
20 V

Max Output Current
480 mA

Operating Supply Voltage
20 V

Output Power
10 W

Min Input Voltage
4.5 V

Max Input Voltage
20 V

Current - Output 1
480 mA

Nominal Input Voltage
12 V

Dimming
PWM

Features
OCP, OVP

Height
15.24 mm

Length
32.004 mm

Width
8.382 mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for TDK LEDC10-12-R48.

Datasheets:

tdklambda-ledc1012r48-datasheets-0441.pdf

tdklambda-ledc1012r48-datasheets-0442.pdf

LEDC10-12-R48 Overview

The LED driver's design uses 1 outputs.Its configuration is based on 11 pins.The mount is on its way to Through Hole.The input voltage must be minimally 4.5 V.It reaches 20 V when the maximum supply current is allowed.It is important that the operating temperature not exceed 85 °C in order to ensure stable operation.Stable operation requires an operating temperature greater than -40 °C.There is 20 V internal voltage required to power systems.Even when operating at a maximal output current of 480 mA, it is capable of delivering all the benefits of a LED driver.The output voltage is 20 V.

LEDC10-12-R48 Features

Operating with the supply voltage of 20 V
Output voltage of 20 V

LEDC10-12-R48 Applications

There are a lot of TDK
LEDC10-12-R48 LED Driver ICs applications.

Refrigeration lighting
Portable lighting
Gallery lighting
Museum lighting
High-end retail lighting
Medical surgery lighting
Replacement lamps
Panel lighting
Down lights
Linear fluorescent
