Description: 12-Channel Low Quiescent Current LED Driver

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

LED1202QTR information

ST LED1202QTR technical specifications, attributes, parameters and parts with similar specifications to ST LED1202QTR.

  • Type
  • Parameter
  • RoHS Status
  • RoHS Compliant
  • Part Life Cycle Code
  • Active
  • Ihs Manufacturer
  • STMICROELECTRONICS
  • Package Description
  • QFN-20
  • Reach Compliance Code
  • compliant
  • ECCN Code
  • EAR99
  • HTS Code
  • 8542.39.00.01
  • Factory Lead Time
  • 16 Weeks
  • Date Of Intro
  • 2019-02-01
  • Samacsys Manufacturer
  • STMicroelectronics
  • Data Input Mode
  • SERIAL
  • Input Characteristics
  • STANDARD
  • Interface IC Type
  • LED DISPLAY DRIVER
  • JESD-30 Code
  • S-XQCC-N20
  • JESD-609 Code
  • e4
  • Length
  • 3 mm
  • Moisture Sensitivity Level
  • 3
  • Multiplexed Display Capability
  • NO
  • Number of Functions
  • 1
  • Number of Segments
  • 12
  • Number of Terminals
  • 20
  • Operating Temperature-Max
  • 85 °C
  • Operating Temperature-Min
  • -40 °C
  • Package Body Material
  • UNSPECIFIED
  • Package Equivalence Code
  • LCC20,.12SQ, 20
  • Package Shape
  • SQUARE
  • Package Style
  • CHIP CARRIER, VERY THIN PROFILE
  • Peak Reflow Temperature (Cel)
  • 260
  • Seated Height-Max
  • 0.6 mm
  • Supply Current-Max
  • 2 mA
  • Supply Voltage-Max
  • 5 V
  • Supply Voltage-Min
  • 2.6 V
  • Supply Voltage-Nom
  • 3.3 V
  • Surface Mount
  • YES
  • Temperature Grade
  • INDUSTRIAL
  • Terminal Finish
  • Nickel/Palladium/Gold (Ni/Pd/Au)
  • Terminal Form
  • NO LEAD
  • Terminal Pitch
  • 0.5 mm
  • Terminal Position
  • QUAD
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Width
  • 3 mm
  • fmax-Min
  • 0.4 MHz
