Manufacturer No:

LD39020ATPU32R

Manufacturer:

ST

Package:

4-XDFN Exposed Pad

Description:

Enable Fixed 0.65mm LD39020 PMIC 4-XDFN Exposed Pad

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

LD39020ATPU32R information

ST LD39020ATPU32R technical specifications, attributes, parameters and parts with similar specifications to ST LD39020ATPU32R.

  • Type
  • Parameter
  • Lifecycle Status
  • ACTIVE (Last Updated: 6 months ago)
  • Factory Lead Time
  • 20 Weeks
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 4-XDFN Exposed Pad
  • Surface Mount
  • YES
  • Operating Temperature
  • -40°C~125°C TJ
  • Packaging
  • Tape & Reel (TR)
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 4
  • ECCN Code
  • EAR99
  • Terminal Position
  • DUAL
  • Terminal Form
  • NO LEAD
  • Peak Reflow Temperature (Cel)
  • NOT SPECIFIED
  • Number of Functions
  • 1
  • Terminal Pitch
  • 0.65mm
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Base Part Number
  • LD39020
  • JESD-30 Code
  • S-PDSO-N4
  • Voltage - Input (Max)
  • 5.5V
  • Output Type
  • Fixed
  • Output Configuration
  • Positive
  • Current - Output
  • 200mA
  • Control Features
  • Enable
  • Input Voltage (Min)
  • 4.2V
  • Voltage - Output (Min/Fixed)
  • 3.2V
  • Number of Regulators
  • 1
  • Protection Features
  • Over Current, Over Temperature, Soft Start
  • Current - Quiescent (Iq)
  • 40μA
  • Voltage Dropout (Max)
  • 0.35V @ 200mA
  • PSRR
  • 80dB ~ 55dB (1kHz ~ 100kHz)
  • Output Voltage1-Max
  • 3.248V
  • Height Seated (Max)
  • 0.4mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for ST LD39020ATPU32R.

Datasheets:

LD39020ATPU32R Overview


The package is delivered in a Tape & Reel (TR) case. In order to package the IC voltage regulator, a 4-XDFN Exposed Pad case is used. On the Voltage regulator IC, there are 4 terminations that can be connected. This IC Regulator has a type of output called Fixed. There are 1 regulators implemented in this electroic component. Surface Mount can be adjusted in the Linear IC in order to vary the temperature range over which Linear Regulator operates. The IC voltage regulator must be maintained at -40°C~125°C TJ degrees for it to function. As you can see, this regulator's output function is configured to be Positive. At present, it can produce an output of up to 200mA. For your information, part number LD39020 is the basic part number for this voltage regulator IC.
