NKK Switches LB15RKW01-5D24-JD

Manufacturer No:

LB15RKW01-5D24-JD

Manufacturer:

NKK Switches

Package:

Description:

Pushbutton Switch,

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

LB15RKW01-5D24-JD information

NKK Switches LB15RKW01-5D24-JD technical specifications, attributes, parameters and parts with similar specifications to NKK Switches LB15RKW01-5D24-JD.

Type
Parameter

Pbfree Code
Yes

RoHS Status
RoHS Compliant

Part Life Cycle Code
Active

Ihs Manufacturer
NKK SWITCHES CO LTD

Reach Compliance Code
compliant

ECCN Code
EAR99

HTS Code
8536.50.70.00

Actuator Length
0.197 inch

Actuator Travel
3 mm

Actuator Type
PUSHBUTTON

Body Breadth
15.8 mm

Body Color
BLACK

Body Height
22.5 mm

Body Length or Diameter
22 mm

Center Contact Plating
SILVER

Contact (AC) Max Rating R Load
3A@250VAC

Contact Current(AC)-Max
3 A

Contact Current(DC)-Max
3 A

Contact (DC) Max Rating R Load
3A@30VDC

Contact Function
ON-(ON)

Contact Resistance
0.05 mΩ

Contact Timing
BREAK-BEFORE-MAKE

Contact Voltage(AC)-Max
250 V

Contact Voltage(DC)-Max
30 V

Electrical Life
100000 Cycle(s)

End Contact Plating
SILVER

Housing Material
GLASS FILLED POLYAMIDE

Illumination
AMBER LED

Insulation Resistance
200000000 Ω

Insulator Material
LIQUID CRYSTAL POLYMER

JESD-609 Code
e4

Mounting Feature
PANEL MOUNT

Operating Force-Max
4.41 N

Operating Temperature-Max
50 °C

Operating Temperature-Min
-25 °C

Sealing
EPOXY TERMINAL SEALED; IP65

Surface Mount
NO

Switch Action
MOMENTARY

Switch Function
SPDT

Switch Type
PUSHBUTTON SWITCH

Terminal Finish
SILVER

Terminal Length
0.295 inch

Terminal Material
PHOSPHOR BRONZE

Termination Type
QUICK CONNECT/SOLDER
