ONSEMI LB11876-TLM-E

Manufacturer No:

LB11876-TLM-E

Manufacturer:

ONSEMI

Package:

36-LSOP (0.220, 5.60mm Width)

Description:

5.6mm mm Motor Drivers 36 12V V Motion Control Electronics

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

LB11876-TLM-E information

ONSEMI LB11876-TLM-E technical specifications, attributes, parameters and parts with similar specifications to ONSEMI LB11876-TLM-E.

Type
Parameter

Lifecycle Status
ACTIVE (Last Updated: 1 week ago)

Factory Lead Time
15 Weeks

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
36-LSOP (0.220, 5.60mm Width)

Number of Pins
36

Operating Temperature
-20°C~85°C TA

Packaging
Tape & Reel (TR)

Published
2007

JESD-609 Code
e6

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
36

Terminal Finish
Tin/Bismuth (Sn/Bi)

Applications
Polygonal Mirror

Subcategory
Motion Control Electronics

Technology
BIPOLAR

Voltage - Supply
4.5V~5.5V 8V~17V

Terminal Position
DUAL

Terminal Form
GULL WING

Supply Voltage
12V

Terminal Pitch
0.8mm

Base Part Number
LB11876

Number of Outputs
1

Operating Supply Voltage
17V

Supply Voltage-Min (Vsup)
8V

Interface
Parallel

Analog IC - Other Type
BRUSHLESS DC MOTOR CONTROLLER

Nominal Supply Current
15mA

Output Configuration
Pre-Driver - Half Bridge (3)

Output Current
20mA

Supply Current-Max (Isup)
25mA

Motor Type - AC, DC
Brushless DC (BLDC)

Width
5.6mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for ONSEMI LB11876-TLM-E.

Datasheets:

onsemiconductor-lb11876tlme-datasheets-4790.pdf

LB11876-TLM-E Overview

This package was designed with Tape & Reel (TR)in mind.36-LSOP (0.220, 5.60mm Width)cases are included with the part.The part should be mounted by Surface Mount.I believe it is suitable for the component connected to Polygonal Mirror.There is a capability for the device to provide 4.5V~5.5V 8V~17V volts.This device operates at a temperature of -20°C~85°C TA.Drivers controllers is possible to classify the motor type as Brushless DC (BLDC).This part provides 36terminations.I would like to remind you that this amplifier should be operated at 12V.The recommended way to mount it is Surface Mount.This device utilizes the BRUSHLESS DC MOTOR CONTROLLERanalog integrated circuit.The LB11876part number allows us to locate it.A device with 36pins is available.Drivers controllers belongs to the Motion Control Electronics series.The available outputs are [0].There is 17V supply voltage required for this driver.With a 20mA output current, it offers the greatest degree of design flexibility.
