LEM LAH 25-NP

Manufacturer No:

LAH 25-NP

Manufacturer:

LEM

Package:

Module

Description:

LAH Series Hall Effect, Closed Loop Sensor 1-Channel Bidirectional -25°C~85°C ±12V~15V DC~200kHz 8A 12A 25A Selectable Accuracy-±0.3% Linearity-±0.2%

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

LAH 25-NP information

LEM LAH 25-NP technical specifications, attributes, parameters and parts with similar specifications to LEM LAH 25-NP.

Type
Parameter

Factory Lead Time
6 Weeks

Mounting Type
Through Hole

Package / Case
Module

Surface Mount
NO

Operating Temperature
-25°C~85°C

Packaging
Bulk

Series
LAH

Published
2007

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Resistance
259Ohm

Voltage - Supply
±12V~15V

Frequency
DC~200kHz

Output
Ratiometric, Current

Current - Supply (Max)
35mA

Body Length or Diameter
33.3mm

Number of Channels
1

Termination Type
SOLDER

Polarization
Bidirectional

Accuracy
±0.3%

Response Time
0.5?s

Sensor Type
Hall Effect, Closed Loop

Linearity
±0.2%

Housing
PLASTIC

For Measuring
AC/DC

Current - Sensing
8A 12A 25A Selectable

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for LEM LAH 25-NP.

Datasheets:

lemusainc-lah25np-datasheets-2244.pdf

LAH 25-NP Overview

Safety measures are taken to protect the current sensors by putting them in Module packages. For protection, these sensors are packaged in the Bulk. Current sensors should only output 35mA current.

LAH 25-NP Features

Moisture Sensitivity Level: 1 (Unlimited)
Operating Temperature: -25°C~85°C
1 Channels
Mounting Type: Through Hole
Sensor Type: Hall Effect, Closed Loop
Supply Voltage: ±12V~15V
Frequency: DC~200kHz
Sensing Current: 8A 12A 25A Selectable
Module Package

LAH 25-NP Applications

There are a lot of LEM USA Inc.
LAH 25-NP Current Sensors applications.

Overcurrent Detection
Frequency, Voltage, and Solar Inverters
Electrical drives
General purpose inverters
AC variable speed drives
Static converters for DC motor drives
Battery supplied applications
Uninterruptible Power Supplies(UPS)
Switched Mode Power Supplies(SMPS)
Power supplies for welding applications
