ST L7805CT

Manufacturer No:

L7805CT

Manufacturer:

Package:

TO-204AA, TO-3

Description:

Fixed L7805 PMIC 2 TO-204AA, TO-3

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

L7805CT information

ST L7805CT technical specifications, attributes, parameters and parts with similar specifications to ST L7805CT.

Type
Parameter

Mount
Through Hole

Mounting Type
Through Hole

Package / Case
TO-204AA, TO-3

Number of Pins
3

Weight
9.071847g

Operating Temperature
0°C~125°C

Packaging
Bulk

Tolerance
5%

JESD-609 Code
e3

Pbfree Code
yes

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
3

ECCN Code
EAR99

Terminal Finish
Tin (Sn)

Subcategory
Other Regulators

Technology
BIPOLAR

Terminal Position
BOTTOM

Terminal Form
PIN/PEG

Number of Functions
1

Base Part Number
L7805

Pin Count
2

JESD-30 Code
O-XBFM-P2

Number of Outputs
1

Output Voltage
5V

Output Type
Fixed

Max Output Current
1.5A

Output Configuration
Positive

Quiescent Current
8mA

Accuracy
4 %

Output Voltage 1
5V

Number of Regulators
1

Min Input Voltage
7V

Protection Features
Over Temperature, Short Circuit

Voltage Dropout (Max)
2V @ 1A Typ

PSRR
62dB (120Hz)

Dropout Voltage
2V

Dropout Voltage1-Nom
2V

Min Output Voltage
4.65V

Power Supply Rejection Ratio (PSRR)
62dB

Nominal Output Voltage
5V

Height
8.7mm

Length
39.5mm

Width
26.2mm

REACH SVHC
No SVHC

Radiation Hardening
No

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for ST L7805CT.

Datasheets:

stmicroelectronics-l7805abd2ttr-datasheets-6961.pdf

L7805CT Overview

Bulk cases are used for delivery. The Liner regulator IC is packaged in TO-204AA, TO-3 case. On the Linear IC itself, there are 3 terminations. Fixed is the output type of the Voltage Regulator IC. As part of this electrical component, 1 regulators are implemented. Variations are made to the Through Hole operating temperature range by the Voltage Regulator IC. Default settings are set to 0°C~125°C degrees. There is a Positive configured as the output function for this IC regulator. There are a total of 2 pins on this board. There are 1 outputs total on this voltage regulator IC in order to ensure that prompt and sufficient performance is achieved. There is a dropout voltage of 10 volts on this IC regulator. Chips have 3 pins. For your information, the basic part number for this regulator IC is L7805. In this case, we have a typical Other Regulators component. In order to meet the operation requirements, its maximal output current reaches 1.5A. It operates in the 8mA Quiescent Current state. This IC regulator has a tolerance of 5%, which is quite low.

L7805CT Features

2V dropout voltage
Other Regulators subtageroy
5% tolerance

L7805CT Applications

There are a lot of STMicroelectronics
L7805CT Linear Voltage Regulators applications.

Battery-powered device
Communication device
Personal communication device
Portable telephone
Electronic notebook
Camera
Video equipment
CPU power supply
Switching regulator
Multiple-power supply system
