ST L6701

Manufacturer No:

L6701

Manufacturer:

Package:

36-BFSOP (0.295, 7.50mm Width) Exposed Pad

Description:

Controller, Intel VR9, VR10, K8 0.8V~1.85V DUAL Specialized Voltage Regulator 0°C~70°C L6701 36 Pins 110kHz 36 Terminations 36-BFSOP (0.295, 7.50mm Width) Exposed Pad

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

L6701 information

ST L6701 technical specifications, attributes, parameters and parts with similar specifications to ST L6701.

Type
Parameter

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
36-BFSOP (0.295, 7.50mm Width) Exposed Pad

Operating Temperature
0°C~70°C

Packaging
Tube

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
36

ECCN Code
EAR99

Applications
Controller, Intel VR9, VR10, K8

Terminal Position
DUAL

Terminal Form
GULL WING

Number of Functions
1

Terminal Pitch
0.5mm

Base Part Number
L6701

Pin Count
36

Number of Outputs
3

Qualification Status
Not Qualified

Input Voltage-Nom
12V

Analog IC - Other Type
SWITCHING REGULATOR

Voltage - Input
12V

Output Current
1.5A

Voltage - Output
0.8V~1.85V

Control Mode
CURRENT-MODE

Switcher Configuration
PHASE-SHIFT

Switching Frequency
110kHz

Height Seated (Max)
2.47mm

Width
7.5mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for ST L6701.

Datasheets:

stmicroelectronics-l6701tr-datasheets-7964.pdf

L6701 Overview

Generally, it supports 3 outputs at a time. The alternator regulator is packaged in a 36-BFSOP (0.295, 7.50mm Width) Exposed Pad container to facilitate transportation. The power regulator is currently available in Tube packages. Volatge output is set to 0.8V~1.85V by this voltage controller. It has a mounting type of Surface Mount. There are a variety of applications for the v, including Controller, Intel VR9, VR10, K8. In order to prevent malfunctions, the operating temperature should be set to 0°C~70°C. It is designed to run the input voltage at 12V. 36 terminals can be found on the electronic component. This part receives much praise as a SWITCHING REGULATOR voltage regulator. This alternator regulator has 36pins in its pinout. If you are trying to find pin-to-pin solutions, try searching L6701. The PCB or other board can be mounted using the Surface Mount on it. The external regulator should be outputting 1.5A at the moment. A frequency of 110kHzcan be set for the AC voltage regulator.

L6701 Features

Widely used in Controller, Intel VR9, VR10, K8 applications
SWITCHING REGULATOR analog IC

L6701 Applications

There are a lot of STMicroelectronics
L6701 Specialized Voltage Regulators applications.

Server DDR Power
Desktop Computer
Graphics Cards
Cell Phones
Wireless Modems
PCS Phones
Two-Way Pagers
PHS Phones
Mobile Radios
Wireless Handsets
