INTEL KU80386EXTC33

Manufacturer No:

KU80386EXTC33

Manufacturer:

INTEL

Package:

QFP

Description:

0.635mm 5V 32-bit Microprocessor 132-Pin 33MHz 5V QFP

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

KU80386EXTC33 information

INTEL KU80386EXTC33 technical specifications, attributes, parameters and parts with similar specifications to INTEL KU80386EXTC33.

Type
Parameter

Mount
Surface Mount

Package / Case
QFP

Number of Pins
132

Packaging
Bulk

Published
1998

JESD-609 Code
e0

Part Status
Discontinued

Number of Terminations
132

ECCN Code
3A001.A.3

Terminal Finish
Tin/Lead (Sn/Pb)

HTS Code
8542.31.00.01

Subcategory
Microprocessors

Technology
CMOS

Terminal Position
QUAD

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Supply Voltage
5V

Terminal Pitch
0.635mm

Frequency
33MHz

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Pin Count
132

Qualification Status
Not Qualified

Operating Temperature (Max)
117°C

Operating Temperature (Min)
-40°C

Power Supplies
5V

Temperature Grade
INDUSTRIAL

Voltage
5V

Max Supply Voltage
5.5V

Min Supply Voltage
4.5V

uPs/uCs/Peripheral ICs Type
MICROPROCESSOR

Supply Current-Max
320mA

Bit Size
32

Access Time
33 μs

Address Bus Width
26

Boundary Scan
YES

Low Power Mode
YES

External Data Bus Width
16

Format
FIXED POINT

Integrated Cache
NO

RAM (words)
0

Number of Serial I/Os
3

Number of External Interrupts
12

Number of DMA Channels
2

Length
24.13mm

Height Seated (Max)
4.57mm

Width
24.13mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for INTEL KU80386EXTC33.

ConflictMineralStatement:

intel-cnla6000pk5-conflictmineralstatement-0045.pdf

KU80386EXTC33 Overview

The embedded microprocessor ships overseas conveniently packed in QFP. A high level of reliability is provided by using an advanced packaging method Bulk. There is MICROPROCESSOR MICROPROCESSOR in the uPs, uCs, or peripheral ICs categories. A total of 132 terminations have been recorded. Turn on the cpu microprocessor and let it run with a 5V voltage supply. There are 32 bits in its architecture. 33MHz is the frequency of the CPU. 132 pin functions are described in the datasheets. As a Microprocessors, this cpu microprocessor is typical. The CPU's external data bus width is 16. Injecting pins into the embedded microprocessor body results in 132 pins. In many applications, this CPU is mounted with a Surface Mount bus. Micro processors can be used from 5V. It is specified in the datasheet that this micro processor requires 5V power supplies. 5V is the voltage on the CPU core. 320mA voltage higher than 320mA can be supplied to the CPU. A voltage higher than 5.5V shouldn't be used in a normal situation. It is recommended that the lowest voltage be fed to the micro processor is 4.5V. Over -40°C is the recommended operating environment. 12 hardware interrupts are terminated externally. The 3 serial I/Os are set to exchange data between peripherals. Programming DMA (Direct Memory Access) is done on the 2 channels.

KU80386EXTC33 Features

32-Bit Structure

KU80386EXTC33 Applications

There are a lot of Intel
KU80386EXTC33 Microprocessor applications.

Toys
Robots
Radio
Television
Heater/Fan
Calculator
Kindle
Christmas lights
3D printers
Washing machine
