Manufacturer No:

KA5M0280RYDTU

Manufacturer:

ONSEMI

Package:

TO-220-4 Full Pack (Formed Leads)

Description:

4 Terminations 8.8V~30V 4 Pin KA5M0280 AC to DC power converter FPS? Series 1 Outputs 67kHz

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

KA5M0280RYDTU information

ONSEMI KA5M0280RYDTU technical specifications, attributes, parameters and parts with similar specifications to ONSEMI KA5M0280RYDTU.

  • Type
  • Parameter
  • Lifecycle Status
  • LAST SHIPMENTS (Last Updated: 2 days ago)
  • Factory Lead Time
  • 2 Weeks
  • Mount
  • Through Hole
  • Mounting Type
  • Through Hole
  • Package / Case
  • TO-220-4 Full Pack (Formed Leads)
  • Number of Pins
  • 4
  • Weight
  • 2.8943g
  • Operating Temperature
  • -25°C~85°C TA
  • Packaging
  • Tube
  • Series
  • FPS?
  • JESD-609 Code
  • e3
  • Pbfree Code
  • yes
  • Part Status
  • Obsolete
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 4
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Tin (Sn)
  • Max Power Dissipation
  • 35W
  • Terminal Position
  • ZIG-ZAG
  • Number of Functions
  • 1
  • Base Part Number
  • KA5M0280
  • Number of Outputs
  • 1
  • Input Voltage-Nom
  • 14V
  • Analog IC - Other Type
  • SWITCHING REGULATOR
  • Power Dissipation
  • 35W
  • Output Current
  • 2A
  • Voltage - Supply (Vcc/Vdd)
  • 8.8V~30V
  • Max Supply Current
  • 12mA
  • Control Features
  • Soft Start
  • Topology
  • Flyback, Forward
  • Control Mode
  • CURRENT-MODE
  • Frequency - Switching
  • 67kHz
  • Input Voltage (Max)
  • 28V
  • Control Technique
  • PULSE WIDTH MODULATION
  • Switcher Configuration
  • SINGLE
  • Max Output Power
  • 14W
  • Internal Switch(s)
  • Yes
  • Fault Protection
  • Current Limiting, Over Load, Over Temperature, Over Voltage
  • Max Duty Cycle
  • 82 %
  • Duty Cycle
  • 77%
  • Voltage - Start Up
  • 15V
  • Min Breakdown Voltage
  • 800V
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for ONSEMI KA5M0280RYDTU.

PCN Obsolescence/ EOL:

PCN Design/Specification:

PCN Packaging:

KA5M0280RYDTU Overview


There is a ac to dc converter embedded in package TO-220-4 Full Pack (Formed Leads) .The ac dc converter is available in Tube case.In this case, the AC/DC converter is mounted in the way of Through Hole .This ac dc converter should be operated at a temperature of -25°C~85°C TA °C so that it can deliver its performance.In this AC DC converter, an analog integrated circuit (IC) of type SWITCHING REGULATOR is employed.When the switching frequency reaches 67kHz , the process is complete.The AC/DC converter is capable of being used when the supply voltage is 8.8V~30V (Vcc/Vdd).There are a total of 4 terminations in it.It contains 4 pins.Through Hole is a suitable mounting point for the ac dc converters.It belongs to a manufacturer family of FPS? .Similar acdc converters can be found using the KA5M0280 family.AC to DC converter is necessary to run 1 outputs.We are setting the output current to 2A .On the basis of a unique technique, it is possible to ensure an input voltage with the maximum value of 28V .Approximately 12mA amps of supply current can be handled by the power AC DC.A maximum output power of 14W can be used with the AC to DC power converter.
