Manufacturer No:

KA339D

Manufacturer:

ONSEMI

Package:

14-SOIC (0.154, 3.90mm Width)

Description:

Surface Mount Tube 18mA mA 1.3 ?s ?s Linear Comparators 106.02dB dB 250nA pA 1.1mA ?A 5mV mV Surface Mount

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

KA339D information

ONSEMI KA339D technical specifications, attributes, parameters and parts with similar specifications to ONSEMI KA339D.

  • Type
  • Parameter
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 14-SOIC (0.154, 3.90mm Width)
  • Number of Pins
  • 14
  • Weight
  • 218.3mg
  • Operating Temperature
  • 0°C~70°C
  • Packaging
  • Tube
  • Pbfree Code
  • yes
  • Part Status
  • Obsolete
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 14
  • Type
  • General Purpose
  • Subcategory
  • Comparator
  • Max Power Dissipation
  • 570mW
  • Terminal Position
  • DUAL
  • Terminal Form
  • GULL WING
  • Number of Functions
  • 4
  • Supply Voltage
  • 5V
  • Terminal Pitch
  • 1.27mm
  • Base Part Number
  • KA339
  • Output Type
  • DTL, MOS, Open-Collector, TTL
  • Operating Supply Voltage
  • 36V
  • Number of Elements
  • 4
  • Nominal Supply Current
  • 1.1mA
  • Output Current
  • 18mA
  • Max Supply Current
  • 2mA
  • Quiescent Current
  • 2.5mA
  • Response Time
  • 1.3 ?s
  • Voltage - Supply, Single/Dual (±)
  • 2V~36V ±1V~18V
  • Output Current per Channel
  • 18mA
  • Input Offset Voltage (Vos)
  • 5mV
  • Voltage Gain
  • 106.02dB
  • Max Input Current
  • 250nA
  • Input Bias Current
  • 250nA
  • Voltage - Input Offset (Max)
  • 5mV @ 5V
  • Current - Input Bias (Max)
  • 0.25?A @ 5V
  • Current - Output (Typ)
  • 18mA @ 5V
  • Length
  • 8.56mm
  • Height Seated (Max)
  • 1.8mm
  • Width
  • 3.975mm
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for ONSEMI KA339D.

Datasheets:

ReachStatement:

KA339D Overview


Electronic comparator is packaged in 14-SOIC (0.154, 3.90mm Width) for convenient transportation.This comparator is of the DTL, MOS, Open-Collector, TTL output type.Ready for shipping in Tube package.You can find 14 terminals of the comparator.Other Comparator like the device play a important role in the industry.Supplied by 5V voltage, the comparator can accomplish the many demanding tasks.Speaking of types, this is a typical General Purpose comparator.This is a 4 element comparator.Surface Mount universial mout for easy adapting.The operating temperature should be set to 0°C~70°C to avoid mal-function.The comparator has 14 pins.Try search KA339 to get more pin-to-pin solutions for your special needs.This comparator presents a quiescent current of 2.5mA .Electronic comparator has a Surface Mount for mounting on PCB or other boards.For normal use of the device, the nominal supply current should be 1.1mA .Current supply exceeding 2mA could cause disfunction of the compartator.The maximal current your can input into the device is 250nA .From the voltage formula, the voltage gain of the part is 106.02dB .Normal operation requires 36V operating supply voltage.

KA339D Features


DTL, MOS, Open-Collector, TTL output capability
General Purpose IC
Employing 4 elements
Operates under 0°C~70°C
Quiescent Current: 2.5mA
Voltage Gain: 106.02dB


KA339D Applications


There are a lot of ON Semiconductor
KA339D linear comparators applications.


  • Mobile Communications
  • Notebooks and PDAs
  • Battery-Powered Electronics
  • General-Purpose Portable Devices
  • General-Purpose, Low-Voltage Applications
  • Self-diagnostics
  • Lithium ion battery monitoring
  • Battery management and protection
  • Current and voltage sensing
  • Analog front end
