C&K JS202011SCQN
C&K JS202011SCQN

C&K JS202011SCQN

Manufacturer No:

JS202011SCQN

Manufacturer:

C&K

Package:

Description:

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

JS202011SCQN information

C&K JS202011SCQN technical specifications, attributes, parameters and parts with similar specifications to C&K JS202011SCQN.

  • Type
  • Parameter
  • Factory Lead Time
  • 13 Weeks
  • Contact Material
  • Copper Alloy
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Number of Pins
  • 6
  • Housing Material
  • Nylon
  • Actuator Material
  • Polyamide (PA46), Nylon 4/6
  • Operating Temperature
  • -40°C~85°C
  • Packaging
  • Cut Tape (CT)
  • Series
  • JS
  • Published
  • 2012
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Termination
  • Gull Wing
  • Number of Positions
  • 2
  • Voltage - Rated DC
  • 6V
  • Current Rating (Amps)
  • 300mA DC
  • Orientation
  • Vertical
  • Depth
  • 7.5mm
  • Current Rating
  • 300mA
  • Contact Finish
  • Silver
  • Termination Style
  • Gull Wing
  • Actuator Type
  • Standard
  • Circuit
  • DPDT
  • Contact Resistance
  • 70mOhm
  • Max Current Rating
  • 300mA
  • Electrical Life
  • 5,000 Cycles
  • Max Voltage Rating (DC)
  • 6V
  • Contact Current Rating
  • 300mA
  • Contact Timing
  • Not Specified
  • Length
  • 9mm
  • Actuator Length
  • 2.00mm
  • REACH SVHC
  • No SVHC
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant
  • Flammability Rating
  • UL94 V-2
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for C&K JS202011SCQN.

Datasheets:

ReachStatement:

Description: The C&K Components JS202011SCQN Slide Switch is a double-pole double-throw (DPDT) switch with a maximum current rating of 300mA and a maximum voltage rating of 6V. It is a miniature, surface-mount switch with a low profile design and a wide range of applications.

Features:
? Low profile design
? Surface-mount
? Double-pole double-throw (DPDT)
? Maximum current rating of 300mA
? Maximum voltage rating of 6V
? RoHS compliant

Applications: The C&K Components JS202011SCQN Slide Switch is suitable for a wide range of applications, including consumer electronics, automotive, industrial, and medical. It is ideal for applications that require a low profile design and a reliable switch with a high current and voltage rating.
