JANS1N6642US Information

Microchip JANS1N6642US technical specifications, attributes, parameters and parts with similar specifications to Microchip JANS1N6642US.

  • Type
  • Parameter
  • Category
  • Discrete Semiconductor Products
  • Manufacturer
  • Microchip Technology
  • Packaging
  • Bulk
  • Part Status
  • Active
  • Manufacturer Lead Time
  • 32 Weeks
  • Capacitance @ Vr, F
  • 5pF @ 0V, 1MHz
  • Current - Average Rectified (Io)
  • 300mA
  • Current - Reverse Leakage @ Vr
  • 500 nA @ 75 V
  • Grade
  • Military
  • Mounting Type
  • Surface Mount
  • Type
  • Parameter
  • Operating Temperature - Junction
  • -65°C ~ 175°C
  • Package / Case
  • D, SQ-MELF
  • Qualification
  • MIL-PRF-19500/578
  • Reverse Recovery Time (trr)
  • 5 ns
  • Speed
  • Fast Recovery =< 500ns, > 200mA (Io)
  • Supplier Device Package
  • D-5D
  • Technology
  • Standard
  • Voltage - DC Reverse (Vr) (Max)
  • 75 V
  • Voltage - Forward (Vf) (Max) @ If
  • 1.2 V @ 100 mA
  • ExportControlClassNumber
  • EAR99

Download datasheets and manufacturer documentation for Microchip JANS1N6642US.

This popular surface mount equivalent JEDEC registered switching/signal diodes are military qualified and available with internal metallurgical bonded construction. These small low capacitance diodes with very fast switching speeds are hermetically sealed and bonded into a “D-5D” package. They may be used in a variety of fast switching applications including computers and peripheral equipment such as magnetic cores, thin-film memories, plated-wire memories, as well as decoding or encoding applications, etc. Microchip also offers a variety of other switching/signal diodes.

  • JEDEC registered surface mount equivalents of 1N6638, 1N6642, and 1N6643
  • Ultra-fast recovery time
  • Very low capacitance
  • Metallurgically bonded
  • Non-cavity glass package
  • JAN, JANTX, JANTXV and JANS qualifications are available per MIL-PRF-19500/578
  • Replacements for 1N4148UR, 1N4148UR-1, 1N4150UR-1, and 1N914UR
  • RoHS compliant devices available (commercial grade only)
  • Small size for high density mounting (see package illustration)
