ONSEMI ISL9R8120P2
ONSEMI ISL9R8120P2

ONSEMI ISL9R8120P2

Manufacturer No:

ISL9R8120P2

Manufacturer:

ONSEMI

Package:

TO-220-2

Description:

Standard Diode Rectifier Fast Recovery =< 500ns, > 200mA (Io) 3.3V @ 8A -55°C~150°C 100?A @ 1200V Tube TO-220-2 Through Hole

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL9R8120P2 information

ONSEMI ISL9R8120P2 technical specifications, attributes, parameters and parts with similar specifications to ONSEMI ISL9R8120P2.

  • Type
  • Parameter
  • Mount
  • Through Hole
  • Mounting Type
  • Through Hole
  • Package / Case
  • TO-220-2
  • Number of Pins
  • 2
  • Weight
  • 2.16g
  • Packaging
  • Tube
  • Series
  • Stealth?
  • Published
  • 2013
  • Pbfree Code
  • yes
  • Part Status
  • Obsolete
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Max Operating Temperature
  • 150°C
  • Min Operating Temperature
  • -55°C
  • Capacitance
  • 30pF
  • Voltage - Rated DC
  • 1.2kV
  • Current Rating
  • 8A
  • Base Part Number
  • ISL9R8120
  • Element Configuration
  • Single
  • Speed
  • Fast Recovery =< 500ns, > 200mA (Io)
  • Diode Type
  • Standard
  • Current - Reverse Leakage @ Vr
  • 100?A @ 1200V
  • Power Dissipation
  • 71W
  • Output Current
  • 8A
  • Voltage - Forward (Vf) (Max) @ If
  • 3.3V @ 8A
  • Operating Temperature - Junction
  • -55°C~150°C
  • Max Surge Current
  • 100A
  • Voltage - DC Reverse (Vr) (Max)
  • 1200V
  • Forward Voltage
  • 3.3V
  • Max Reverse Voltage (DC)
  • 1.2kV
  • Average Rectified Current
  • 8A
  • Reverse Recovery Time
  • 300ns
  • Peak Reverse Current
  • 100?A
  • Max Repetitive Reverse Voltage (Vrrm)
  • 1.2kV
  • Capacitance @ Vr, F
  • 30pF @ 10V 1MHz
  • Peak Non-Repetitive Surge Current
  • 100A
  • Reverse Voltage
  • 1.2kV
  • Max Forward Surge Current (Ifsm)
  • 100A
  • Recovery Time
  • 44 ns
  • Height
  • 6.35mm
  • Length
  • 6.35mm
  • Width
  • 6.35mm
  • REACH SVHC
  • No SVHC
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for ONSEMI ISL9R8120P2.

Datasheets:

ISL9R8120P2 Overview


1.2kV is a reasonable reverse voltage.There is an average rectified current of 8A volts for this device.This electronic or electrical device produces 71W heat as an unwanted derivative of its primary action.The allowable value of forward current reaches 8A.Its current rating is 8A, which is the maximum current that a fuse will carry for an indefinite period without too much deterioration of the fuse element. 100A is the maximum value of surge current that can be used.Depending on the capacitance, the device can deliver a value of 30pF.In the datasheets, the peak reverse is 100?A, as indicated by the data chart.

ISL9R8120P2 Features


an average rectified current of 8A volts
a current rating of 8A
the peak reverse is 100?A


ISL9R8120P2 Applications


There are a lot of ON Semiconductor
ISL9R8120P2 applications of single-phase diode rectifier.


  • DC motor control and drives
  • Battery chargers
  • Welders
  • Power converters
  • Reverse Polarity Protection
  • Ultra High-Speed Switching
  • Freewheeling
  • Polarity Protection Diode
  • Recirculating Diode
  • Switching Diode
