Renesas ISL9220BIRTZ-T

Manufacturer No:

ISL9220BIRTZ-T

Manufacturer:

Renesas

Package:

Description:

4.5/14V 1 Channel QUAD Battery Management ICs 5V

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL9220BIRTZ-T information

Renesas ISL9220BIRTZ-T technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL9220BIRTZ-T.

Type
Parameter

Mount
Surface Mount

Published
2010

Number of Terminations
20

ECCN Code
EAR99

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

Additional Feature
SEATED HGT-NOM

HTS Code
8542.39.00.01

Subcategory
Power Management Circuits

Terminal Position
QUAD

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Number of Functions
1

Supply Voltage
5V

Terminal Pitch
0.5mm

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Pin Count
20

JESD-30 Code
S-PQCC-N20

Qualification Status
Not Qualified

Supply Voltage-Max (Vsup)
14V

Power Supplies
4.5/14V

Temperature Grade
INDUSTRIAL

Supply Voltage-Min (Vsup)
4.5V

Number of Channels
1

Adjustable Threshold
YES

Supply Current-Max (Isup)
15mA

Length
4mm

Height Seated (Max)
0.75mm

Width
4mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Renesas ISL9220BIRTZ-T.

ISL9220BIRTZ-T Overview

This power management IC utilizes an analog IC POWER SUPPLY SUPPORT CIRCUIT. A total of 1 channels are available. You can mount this electronic part by using Surface Mount. An electronic component in this family is a Power Management Circuits. Activation of this smart tools battery requires a value greater than 0. It should be used at temperatures below 85°C. Voltage 4.5/14V is used to power it. It is always recommended that this battery protection IC is set to 5V. The pins on it total 20. Using this battery instrument, you can discover a value of SEATED HGT-NOM. There is a maximum supply voltage (Vsup) of 14V. A voltage greater than 4.5V must be present in Vsup (supply voltage). A maximum current supply (Isup) of 15mA is permitted.

ISL9220BIRTZ-T Features

operate supply voltage at the range of 5V
Supply Voltage-Max (Vsup) : 14V

ISL9220BIRTZ-T Applications

There are a lot of Intersil (Renesas Electronics America)
ISL9220BIRTZ-T Battery Management ICs applications.

Golf carts
Electric-powered machinery
Fork lifts
Grid power infrastructure
Cell phone towers
A/C power substations
Internet infrastructure equipment
Aviation ground support systems
Tower communications
Weather stations
