Renesas ISL9216IRZ

Manufacturer No:

ISL9216IRZ

Manufacturer:

Renesas

Package:

32-VFQFN Exposed Pad

Description:

-40°C~85°C TA 3 Channel QUAD Battery Management ICs ISL9216 8 ~ 12 Cell Lithium-Ion 32-VFQFN Exposed Pad

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL9216IRZ information

Renesas ISL9216IRZ technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL9216IRZ.

Type
Parameter

Mounting Type
Surface Mount

Package / Case
32-VFQFN Exposed Pad

Surface Mount
YES

Operating Temperature
-40°C~85°C TA

Packaging
Tube

JESD-609 Code
e3

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
2 (1 Year)

Number of Terminations
32

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn)

HTS Code
8542.39.00.01

Terminal Position
QUAD

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Terminal Pitch
0.5mm

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Base Part Number
ISL9216

JESD-30 Code
S-PQCC-N32

Function
Battery Protection

Supply Voltage-Max (Vsup)
30.1V

Supply Voltage-Min (Vsup)
9.2V

Number of Channels
3

Interface
I2C

Adjustable Threshold
YES

Fault Protection
Over Current, Short Circuit

Battery Chemistry
Lithium-Ion

Number of Cells
8 ~ 12

Length
4.75mm

Height Seated (Max)
1mm

Width
4.75mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Renesas ISL9216IRZ.

ISL9216IRZ Overview

This package corresponds to 32-VFQFN Exposed Pad. POWER SUPPLY SUPPORT CIRCUIT is the analog IC used by this power management IC. It is possible to access 3 channels. A Tube case holds it. There is a electronic part mounted in the way of Surface Mount. In addition to Battery Protection functions, it can deliver other functions as well. When a electronic part is operated at -40°C~85°C TA, its performance will be optimal. This electronic part includes a Lithium-Ion chemistry battery. There is a ISL9216 family at the core of it. 30.1V is the maximal voltage supply (Vsup). Ideally, Vsup (supply voltage) should be greater than 9.2V.
