Renesas ISL9203CRZ-TR5220

Manufacturer No:

ISL9203CRZ-TR5220

Manufacturer:

Renesas

Package:

DFN

Description:

5V 1 Channel DUAL Battery Management ICs 5V 10 Pins 1 Cell DFN

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL9203CRZ-TR5220 information

Renesas ISL9203CRZ-TR5220 technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL9203CRZ-TR5220.

Type
Parameter

Mount
Surface Mount

Package / Case
DFN

Number of Pins
10

Packaging
Cut Tape

Published
2003

JESD-609 Code
e3

Part Status
Active

Moisture Sensitivity Level (MSL)
2 (1 Year)

Number of Terminations
10

Termination
SMD/SMT

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn) - annealed

Max Operating Temperature
70°C

Min Operating Temperature
-20°C

Subcategory
Power Management Circuits

Technology
MOS

Terminal Position
DUAL

Terminal Form
FLAT

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Supply Voltage
5V

Terminal Pitch
0.5mm

Time@Peak Reflow Temperature-Max (s)
40

Pin Count
10

Temperature Grade
COMMERCIAL

Number of Channels
1

Max Supply Voltage
6.5V

Min Supply Voltage
4.3V

Analog IC - Other Type
POWER SUPPLY SUPPORT CIRCUIT

Current - Output
1.6A

Adjustable Threshold
NO

Max Output Voltage
4.242V

Voltage - Output
4.2V

Max Input Voltage
6.5V

Supply Current-Max (Isup)
2mA

Nominal Input Voltage
6.5V

Number of Cells
1

Charge Current - Max
1.5A

Length
3mm

Width
3mm

REACH SVHC
No SVHC

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for Renesas ISL9203CRZ-TR5220.

Datasheets:

intersil-isl9203crztr5220-datasheets-6803.pdf

ISL9203CRZ-TR5220 Overview

It is appropriate for the DFN package. POWER SUPPLY SUPPORT CIRCUIT is the analog IC that this power IC employs. There are 1 channels available. It has a total of 10 pins. It's packaged in a Cut Tape case. Use Surface Mount to mount this electronic component. This electrical part's minimum supply voltage should not be less than 4.3V volts. This electrical component is from the Power Management Circuits family. This power IC's supplied voltage should not exceed 6.5V volts. To activate this power management IC, it should not be less than -20°C. It is suggested that it be used at temperatures below 70°C. It is powered by a 5V volts. Keep in mind that this battery management IC should be set to 5V at all times. There are a total of 10 pins on it. The maximum supply current (Isup) must not exceed 2mA. Its output voltage amounts to 4.2V. It is available to power the battery instrument input voltage under 6.5V. For the battery safety, it is recommended to power the battert under 1.5A.
