Renesas ISL90840UIV2027ZT2

Manufacturer No:

ISL90840UIV2027ZT2

Manufacturer:

Renesas

Package:

TSSOP

Description:

20 Terminations 3.3V 20 Pin Digital Potentiometers I2C 256 Positions Min 2.7V V Max 5.5V V

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL90840UIV2027ZT2 information

Renesas ISL90840UIV2027ZT2 technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL90840UIV2027ZT2.

Type
Parameter

Mount
Surface Mount

Package / Case
TSSOP

Number of Pins
20

Weight
190.990737mg

Published
2004

JESD-609 Code
e3

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
20

ECCN Code
EAR99

Temperature Coefficient
45 ppm/°C

Resistance
50kOhm

Number of Positions
256

Terminal Finish
MATTE TIN

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

Subcategory
Digital Potentiometers

Technology
CMOS

Terminal Position
DUAL

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
260

Number of Functions
4

Supply Voltage
3.3V

Terminal Pitch
0.65mm

Time@Peak Reflow Temperature-Max (s)
40

Qualification Status
Not Qualified

Operating Supply Voltage
5V

Temperature Grade
INDUSTRIAL

Interface
I2C

Number of Circuits
4

Max Supply Voltage
5.5V

Min Supply Voltage
2.7V

Operating Supply Current
1mA

Memory Type
Volatile

Converter Type
DIGITAL POTENTIOMETER

Supply Type
Single

Taper
Linear

Number of Taps
256

Total Resistance
50000Ohm

Height
1.05mm

Length
6.6mm

Width
4.5mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Renesas ISL90840UIV2027ZT2.

Datasheets:

intersil-isl90840uiv2027zt2-datasheets-0919.pdf

ISL90840UIV2027ZT2 Overview

TSSOP packages contain it.Volatile marks the beginning of the storage process for this pentometer.The digital potentiometer has 4 embedded circuits.This pentometer is protected from overcurrent by 256 taps.The number of positions is 256.There are 20 terminations on this digital potentiometer.You can refer to 4 functions in this programmable potentiometer.According to the diagram, the speed potentiometers's total resistance is 50000Ohm.Powered by 3.3V, it delivers its performance.In the digi devices, there are 20 pins.A flow limit of 50kOhm can be applied.Mounted by Surface Mount.Digital potentiometer has 20 pins.There is a DIGITAL POTENTIOMETER classification for its converter type.A supply voltage of 5V conducts the potentiometer.A maximum 85°C ensures that the digital resistor runs smoothly.In order to maintain reliability, it is operated at a minimum temperature of -40°C.This electronic component belongs to the family Digital Potentiometers.The maximum supply voltage it can handle is 5.5V.A electronic potentiometer minimum supply voltage of 2.7V can be used.The supply current needs to be operated in the range of 1mA.It is possible to categorize supplies by Single.

ISL90840UIV2027ZT2 Features

Available in TSSOP package
4 Circuits
20 pins
Operate supply voltage at the range of 5V

ISL90840UIV2027ZT2 Applications

There are a lot of Intersil (Renesas Electronics America)
ISL90840UIV2027ZT2 Digital Potentiometers applications.

Cell phone
Household appliances
Modern office equipment
Industrial control
Medical equipment
Refrigerator
Programmable computer
Power supply
Power meter
Automatic detection of equipment
