ISL89166FBEAZ-T information

Renesas ISL89166FBEAZ-T technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL89166FBEAZ-T.

  • Type
  • Parameter
  • Mount
  • Surface Mount
  • Package / Case
  • SOIC
  • Number of Pins
  • 8
  • Packaging
  • Tape & Reel (TR)
  • Published
  • 2010
  • JESD-609 Code
  • e3
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 8
  • Terminal Finish
  • Matte Tin (Sn) - annealed
  • Max Operating Temperature
  • 125°C
  • Min Operating Temperature
  • -40°C
  • Subcategory
  • MOSFET Drivers
  • Terminal Position
  • DUAL
  • Terminal Form
  • GULL WING
  • Peak Reflow Temperature (Cel)
  • 260
  • Supply Voltage
  • 12V
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Qualification Status
  • Not Qualified
  • Max Output Current
  • 6A
  • Max Supply Voltage
  • 16V
  • Min Supply Voltage
  • 4.5V
  • Power Dissipation-Max
  • 2.27W
  • Operating Supply Current
  • 5mA
  • Turn On Delay Time
  • 25 ns
  • Rise Time
  • 20ns
  • Fall Time (Typ)
  • 20 ns
  • Turn-Off Delay Time
  • 25 ns
  • Interface IC Type
  • AND GATE BASED MOSFET DRIVER
  • Number of Drivers
  • 2
  • Width
  • 3.9005mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for Renesas ISL89166FBEAZ-T.

Datasheets:

ISL89166FBEAZ-T Overview


A higher degree of flexibility is achieved by adopting its SOIC package.Tape & Reel (TR) represents the packaging method.This device is equipped with 2 drivers for its configuration.It's configured with 8 terminations.The device is mounted with Surface Mount.There are 8 pins available in the device.Mosfet driver is designed specifically to run on 12V volts of power.The interface IC is referred to as AND GATE BASED MOSFET DRIVER.There is a maximum output current of 6A that can be achieved.Mosfet driver includes a number of useful electronic components in Mosfet drivers subcategory of MOSFET Drivers.A maximum operating temperature of 125°C is permissible.There is a minimum operating temperature of -40°C.When the supply voltage is 16V, it is at its maximum operation.In order for the device to operate, a supply voltage of 4.5V must be applied.Mosfet gate drivers outputs a current of 6A at the moment.The device operates on a voltage of 5mA as the supply voltage.

ISL89166FBEAZ-T Features


Embedded in the Tape & Reel (TR) package
2 drivers
8 pins


ISL89166FBEAZ-T Applications


There are a lot of Intersil (Renesas Electronics America)
ISL89166FBEAZ-T gate drivers applications.


  • Broadcast equipment
  • Active filtering
  • Head-up and Head mounted displays
  • High current laser/LED systems
  • LCD/LCoS/DLP portable and embedded pico projectors
  • Multicolor LED/laser displays
  • Smart Phones
  • Portable Navigation Devices
  • Portable Media Players
  • Motor Controls
