Renesas ISL8844AMUZ-T

Manufacturer No:

ISL8844AMUZ-T

Manufacturer:

Renesas

Package:

MSOP

Description:

8 Terminations 8 Pin AC to DC power converter 1 Outputs 2MHz

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL8844AMUZ-T information

Renesas ISL8844AMUZ-T technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL8844AMUZ-T.

Type
Parameter

Factory Lead Time
17 Weeks

Mount
Surface Mount

Package / Case
MSOP

Number of Pins
8

Published
2007

JESD-609 Code
e3

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
8

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn) - annealed

Max Operating Temperature
125°C

Min Operating Temperature
-55°C

Subcategory
Switching Regulator or Controllers

Terminal Position
DUAL

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Terminal Pitch
0.65mm

Time@Peak Reflow Temperature-Max (s)
40

Pin Count
8

Number of Outputs
1

Qualification Status
Not Qualified

Temperature Grade
MILITARY

Analog IC - Other Type
SWITCHING REGULATOR

Current - Output
1A

Input Voltage (Min)
9.6V

Topology
Boost, Flyback

Control Mode
CURRENT-MODE

Frequency - Switching
2MHz

Input Voltage (Max)
30V

Control Technique
PULSE WIDTH MODULATION

Rise Time
20ns

Switcher Configuration
SINGLE

Max Duty Cycle
48 %

Duty Cycle (Max)
48 %

Length
3mm

Width
3mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Renesas ISL8844AMUZ-T.

ISL8844AMUZ-T Overview

It is embedded in package MSOP .Analog IC type SWITCHING REGULATOR is utilized in this AC DC converter.As a result, the switching frequency reaches 2MHz .There have been 8 terminations of this program.Approximately 8 pins are present on the ac/dc converter.The pins of the ac-dc converter total to 8 .The ac dc converters is suitable for mounting by Surface Mount .In this AC to DC transformer, there are 1 outputs to run.There are a ac to dc conversions included in Switching Regulator or Controllers .Using a unique technique, a voltage with a maximum value of 30V can be ensured.When 125°C is set to the maximum, the AC to DC power converter will run continuously.There must be a minimum working temperature of -55°C for this isolated switch.It provides maximum design flexibility due to its 1A output current.
