Renesas ISL84781IR-T

Manufacturer No:

ISL84781IR-T

Manufacturer:

Renesas

Package:

QFN

Description:

QUAD Analog Switches BREAK-BEFORE-MAKE 16 Pins 1.8V QFN

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL84781IR-T information

Renesas ISL84781IR-T technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL84781IR-T.

Type
Parameter

Mount
Surface Mount

Package / Case
QFN

Number of Pins
16

Packaging
Tape & Reel (TR)

Published
2003

JESD-609 Code
e0

Part Status
Discontinued

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
16

Resistance
750mOhm

Terminal Finish
Tin/Lead (Sn/Pb)

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

Subcategory
Multiplexer or Switches

Technology
CMOS

Terminal Position
QUAD

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
240

Number of Functions
1

Supply Voltage
1.8V

Terminal Pitch
0.5mm

Reach Compliance Code
not_compliant

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Pin Count
16

Supply Voltage-Max (Vsup)
3.6V

Temperature Grade
INDUSTRIAL

Number of Channels
1

Number of Circuits
1

Operating Supply Current
50nA

Throw Configuration
DPST

Logic Function
Demultiplexer, Multiplexer

Supply Type
Single

On-state Resistance Match-Nom
0.1Ohm

Switching
BREAK-BEFORE-MAKE

Switch-on Time-Max
33ns

Switch-off Time-Max
25ns

Signal Current-Max
0.3A

Length
3mm

Width
3mm

RoHS Status
RoHS Compliant

Lead Free
Contains Lead

Download datasheets and manufacturer documentation for Renesas ISL84781IR-T.

Datasheets:

intersil-isl84781irt-datasheets-5139.pdf

ISL84781IR-T Overview

Presented in QFN, this electrical component is convenient for overseas shipping. High reliability is ensured by the advanced packaging method Tape & Reel (TR). Totally, there are 16 terminations. A high-quality output is provided by the electrical component's 1 channels. It is safe to turn on and run the electronic component with a 1.8V voltage supply. A total of 16 pins are injected into the electrical part body. The circuits in this analogue multiplexer number 1. In this multiplexer, the internal resistance is 750mOhm. For details about the functions of 16 pins, please refer to the datasheets. There is Multiplexer or Switches analog multiplexer like this in the world. The digital multiplexer has a low cost Single supply. For this digital switch to work, 50nA current would suffice. An environment with a temperature greater than 85°C should not be used to operate the digital switches.

ISL84781IR-T Features

1 Channels
50nA Supply Current

ISL84781IR-T Applications

There are a lot of Intersil (Renesas Electronics America)
ISL84781IR-T Analog Switches & Multiplexers ICs applications.

Precision data acquisition
Battery-powered systems
Sample-and-hold systems
Communication systems
Data Acquisition Systems
Relay Replacement
Battery Powered Systems
Existing multiplexer applications (both fault-protected and nonfault-protected)
New designs requiring multiplexer functions
Cellular phones
