Renesas ISL78215AUZ
Manufacturer No:
ISL78215AUZ
Manufacturer:
Package:
MSOP
Description:
8 Terminals 8-Pin DC to DC converter IC SWITCHING CONTROLLER 1 Outputs 2MHz
Quantity:
Delivery:
Payment:
In Stock :Available
Price not displayed? Please send an RFQ, and we will respond immediately.
ISL78215AUZ information
Renesas ISL78215AUZ technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL78215AUZ.
- Type
- Parameter
- Factory Lead Time
- 9 Weeks
- Mount
- Surface Mount
- Package / Case
- MSOP
- Number of Pins
- 8
- Published
- 2001
- JESD-609 Code
- e3
- Part Status
- Active
- Moisture Sensitivity Level (MSL)
- 1 (Unlimited)
- Number of Terminations
- 8
- ECCN Code
- EAR99
- Terminal Finish
- Matte Tin (Sn) - annealed
- Max Operating Temperature
- 105°C
- Min Operating Temperature
- -40°C
- Additional Feature
- ALSO OPERATES IN CURRENT MODE
- Subcategory
- Switching Regulator or Controllers
- Technology
- BICMOS
- Terminal Position
- DUAL
- Terminal Form
- GULL WING
- Peak Reflow Temperature (Cel)
- 260
- Number of Functions
- 1
- Terminal Pitch
- 0.65mm
- Time@Peak Reflow Temperature-Max (s)
- 30
- Pin Count
- 8
- Number of Outputs
- 1
- Input Voltage-Nom
- 15V
- Temperature Grade
- INDUSTRIAL
- Analog IC - Other Type
- SWITCHING CONTROLLER
- Current - Output
- 1A
- Frequency (Max)
- 2MHz
- Input Voltage (Min)
- 6.9V
- Control Mode
- VOLTAGE-MODE
- Frequency - Switching
- 2MHz
- Control Technique
- PULSE WIDTH MODULATION
- Rise Time
- 20ns
- Switcher Configuration
- PUSH-PULL
- Max Duty Cycle
- 48 %
- Duty Cycle (Max)
- 48 %
- Length
- 3mm
- Width
- 3mm
- RoHS Status
- RoHS Compliant
Download datasheets and manufacturer documentation for Renesas ISL78215AUZ.
ISL78215AUZ Overview
With a MSOP package, the switching controller is suitable for a wide range of applications. For 1 outputs, the dc motor controller is appropriate. Switching can be done at 2MHz with this switching controller. A SWITCHING CONTROLLER analog IC is connected to the switch converters. The switching converters's terminals (s) are designed at DUAL. An array of 8 terminations of dc switching. These dc dc converter ics adapt a variety of control techniques, including PULSE WIDTH MODULATION. The nominal DC switcher's voltage input is 15V. There are a total of 8 pins on switching converter. In particular, switching converter is a type of Switching Regulator or Controllers. It is recommended that the input voltage of the dc dc voltage regulator be 6.9V. It is set to 48 % duty cycle to ensure voltage regulator dc to dc reliability during power-ups and power-downs. In most applications and prototypes, DC switcher's Surface Mount makes it suitable. To better satisfy the need, DC to DC voltage regulator has a value of ALSO OPERATES IN CURRENT MODE. Ideally, dc regulator should be kept at a temperature of -40°C or higher. The temperature should not exceed 105°C degrees Celsius. In total, the switch converters have 1 function (s). We are designing chips that have 8 pins. There is a maximum frequency of 2MHz that the controller can switch at. Switching controllers with 1A inputs are ideal for it.
