Renesas ISL6532ACR

Manufacturer No:

ISL6532ACR

Manufacturer:

Renesas

Package:

VQFN

Description:

28 Terminations Specialized Power Management ICs 1 Functions

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL6532ACR information

Renesas ISL6532ACR technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL6532ACR.

Type
Parameter

Mount
Surface Mount

Package / Case
VQFN

Published
2001

JESD-609 Code
e0

Pbfree Code
no

Part Status
Discontinued

Moisture Sensitivity Level (MSL)
2 (1 Year)

Number of Terminations
28

ECCN Code
EAR99

Terminal Finish
Tin/Lead (Sn/Pb)

Max Operating Temperature
70°C

Min Operating Temperature
0°C

HTS Code
8542.39.00.01

Subcategory
Switching Regulator or Controllers

Terminal Position
QUAD

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
240

Number of Functions
1

Terminal Pitch
0.65mm

Reach Compliance Code
not_compliant

Time@Peak Reflow Temperature-Max (s)
30

Pin Count
28

JESD-30 Code
S-PQCC-N28

Qualification Status
Not Qualified

Temperature Grade
COMMERCIAL

Analog IC - Other Type
SWITCHING CONTROLLER

Operating Supply Current
5.25mA

Input Voltage (Min)
4.5V

Control Mode
VOLTAGE-MODE

Output Current-Max
3A

Input Voltage (Max)
5.5V

Control Technique
PULSE WIDTH MODULATION

Switcher Configuration
PUSH-PULL

Switching Frequency-Max
280kHz

Length
6mm

Height Seated (Max)
1mm

Width
6mm

RoHS Status
RoHS Compliant

Lead Free
Contains Lead

Download datasheets and manufacturer documentation for Renesas ISL6532ACR.

Datasheets:

intersil-isl6532acr-datasheets-7163.pdf

intersil-isl6532acr-datasheets-5642.pdf

ISL6532ACR Overview

A convenient transport package is provided in VQFN .It is possible to find 28 terminals on the power ic.The instruments designs has received high praise because it is an analog SWITCHING CONTROLLER IC.This connector has a Surface Mount for mounting it on a PCB or other type of board.Power ic pinouts begin with 28 pins.It operates at 5.25mA volts.This is ics supply of the series Switching Regulator or Controllers .There is no benefit to raising the temperature above 70°C .The temperature must not be lower than 0°C .
