Renesas ISL6225CAZ-T

Manufacturer No:

ISL6225CAZ-T

Manufacturer:

Renesas

Package:

QSOP

Description:

5.5V 260 Cel DUAL Specialized Voltage Regulator 28 Pins 28 Terminations QSOP

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL6225CAZ-T information

Renesas ISL6225CAZ-T technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL6225CAZ-T.

Type
Parameter

Mount
Surface Mount

Package / Case
QSOP

Number of Pins
28

Published
2002

JESD-609 Code
e3

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
28

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn) - annealed

Max Operating Temperature
85°C

Min Operating Temperature
-10°C

Subcategory
Switching Regulator or Controllers

Terminal Position
DUAL

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Terminal Pitch
0.635mm

Time@Peak Reflow Temperature-Max (s)
40

Pin Count
28

Number of Outputs
2

Operating Supply Voltage
5V

Input Voltage-Nom
5V

Temperature Grade
OTHER

Analog IC - Other Type
DUAL SWITCHING CONTROLLER

Voltage - Output
5.5V

Control Mode
CURRENT-MODE

Frequency - Switching
300kHz

Control Technique
PULSE WIDTH MODULATION

Switcher Configuration
PUSH-PULL

Length
9.905mm

Height Seated (Max)
1.75mm

Width
3.895mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for Renesas ISL6225CAZ-T.

Datasheets:

intersil-isl6225cazt-datasheets-7188.pdf

ISL6225CAZ-T Overview

There are 2 outputs supported by the voltage regulator. Transport is made easy with the package of QSOP. Volatge output for this voltage controller is 5.5V. It contains terminals with the number 28. The part has received praise for being a DUAL SWITCHING CONTROLLER voltage regulator. Initially, the pinout of the alternator regulator begins with 28 pins. Surface Mount is there for mounting on a PCB or another board. There are 28 pins on the power supply regulator. The AC voltage regulator and other Switching Regulator or Controllers play an important role in the industry. It cannot be operated at temperatures below -10°C. In general, temperatures higher than 85°Care not recommended. It is necessary to have an operating supply voltage of 5V for normal operation. In this voltage regulator, the switching frequency is set to 300kHz.
