Renesas ISL6225CAZ

Manufacturer No:

ISL6225CAZ

Manufacturer:

Renesas

Package:

SSOP

Description:

5.5V 260 Cel DUAL Specialized Voltage Regulator 28 Pins 28 Terminations SSOP

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL6225CAZ information

Renesas ISL6225CAZ technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL6225CAZ.

Type
Parameter

Mount
Surface Mount

Package / Case
SSOP

Number of Pins
28

Published
2002

JESD-609 Code
e3

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
28

Termination
SMD/SMT

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn) - annealed

Max Operating Temperature
85°C

Min Operating Temperature
-10°C

Subcategory
Switching Regulator or Controllers

Terminal Position
DUAL

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Terminal Pitch
0.635mm

Frequency
300kHz

Time@Peak Reflow Temperature-Max (s)
30

Pin Count
28

Number of Outputs
2

Output Type
Voltage

Max Output Current
8A

Input Voltage-Nom
5V

Temperature Grade
OTHER

Max Supply Voltage
5.25V

Min Supply Voltage
4.75V

Analog IC - Other Type
DUAL SWITCHING CONTROLLER

Current - Output
8A

Max Output Voltage
5.5V

Voltage - Output
5.5V

Control Mode
CURRENT-MODE

Frequency - Switching
300kHz

Max Input Voltage
24V

Control Technique
PULSE WIDTH MODULATION

Nominal Input Voltage
24V

Switcher Configuration
PUSH-PULL

Length
9.905mm

Height Seated (Max)
1.75mm

Width
3.895mm

REACH SVHC
No SVHC

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for Renesas ISL6225CAZ.

Datasheets:

intersil-isl6225caz-datasheets-7115.pdf

ISL6225CAZ Overview

It supports 2 outputs in total. It is packaged in SSOP for convenient transportation. This power supply regulator has a general volatge output of 5.5V. You can find 28 terminals of the voltage regulator. As a DUAL SWITCHING CONTROLLER regulator, the electronic part has received lots of praise. The pinout of the rectifier regulator starts from 28 pins it has. It has a Surface Mount for mounting on PCB or other boards. The power regulator has 28 pins. Other Switching Regulator or Controllers like the voltage controller play a important role in the industry. Temperature lower than -10°C is not suitable for the it. Temperature higher than 85°C is not recommended. Normal operation requires 5V operating supply voltage. The voltage regulator is designed to produce current 8A at its maximum. This power supply regulator allows minimum supply voltage of 4.75V. The maximal supply voltage of the voltage controller is 5.25V. This AC voltage regulator comes in a 300kHz switching frequency. This shunt regulator operates across a range of frequencies 300kHz.

ISL6225CAZ Features

DUAL SWITCHING CONTROLLER analog IC
Supply voltage: 5V
Switching at 300kHz

ISL6225CAZ Applications

There are a lot of Intersil (Renesas Electronics America)
ISL6225CAZ Specialized Voltage Regulators applications.

Memory Termination Regulator for DDR, DDR2, DDR3, and Low Power DDR3/DDR4
Notebook/Desktop/Server
Telecom/Datacom
GSM Base Station
LCD-TV/PDP-TV
Copier/Printer
Set-Top Box
DDR Vooo and V? Voltage Generation
PC Dual Power Supply
Server DDR Power

User Guide
