Renesas ISL59444IBZ-T7

Manufacturer No:

ISL59444IBZ-T7

Manufacturer:

Renesas

Package:

SOIC

Description:

4 Channels 180mA per Channel Instrumentational OP Amps 5V 16 Pins SOIC

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL59444IBZ-T7 information

Renesas ISL59444IBZ-T7 technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL59444IBZ-T7.

Type
Parameter

Mount
Surface Mount

Package / Case
SOIC

Number of Pins
16

Packaging
Tape & Reel

Published
2005

JESD-609 Code
e3

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
16

Terminal Finish
Matte Tin (Sn) - annealed

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

Subcategory
Multiplexer or Switches

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Supply Voltage
5V

Time@Peak Reflow Temperature-Max (s)
40

Pin Count
16

Operating Supply Voltage
5V

Temperature Grade
AUTOMOTIVE

Number of Channels
4

Number of Circuits
1

Analog IC - Other Type
VIDEO MULTIPLEXER

Throw Configuration
4PST

Propagation Delay
880 ps

Turn On Delay Time
32 ns

Slew Rate
1515 V/μs

Output Current per Channel
180mA

Supply Type
Dual

Bandwidth
1 GHz

Neg Supply Voltage-Nom (Vsup)
-5V

Turn-Off Delay Time
29 ns

Max Dual Supply Voltage
5.5V

-3db Bandwidth
1 GHz

Dual Supply Voltage
5V

Off-state Isolation-Nom
75 dB

Length
9.906mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for Renesas ISL59444IBZ-T7.

ISL59444IBZ-T7 Overview

Packaging for the buffer amplifier is in the form of a SOIC case. There is a Tape & Reel case that is delivered with the instrumentation amplifiers. A total of 16 terminations have been reported in the past few weeks. Buffer amplifier has a total of 16 pins on it. I would like you to keep in mind that this buffer amplifier needs to be run at a voltage of 5V. In more specific terms, this linear amplifier can be categoriMultiplexer or Switchesed as a Multiplexer or Switches-type device. An 16-pin op amp ic is included in the package. Using a supply current of 18mA , this buffer op amp will be able to operate. The buffer amp consists of 1 circuits in total. 4 channels are available on the instrumentation amplifier. This op amp needs to be operated at a temperature of not less than -40°C degrees Celsius in order to function properly. You should not use op amp above 85°C degrees. The operating supply voltage of the buffer op amp is rated at 5V. This electronic part should be conducted with a dual supply voltage of 5.5V volts for this part. An analog IC that is also used in this instrumentation amplifier is referred to as the VIDEO MULTIPLEXER type.
