Renesas ISL5729IN

Manufacturer No:

ISL5729IN

Manufacturer:

Renesas

Package:

LQFP

Description:

DAC 7mm mm

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL5729IN information

Renesas ISL5729IN technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL5729IN.

Type
Parameter

Mount
Surface Mount

Package / Case
LQFP

Packaging
Bulk

Published
2001

JESD-609 Code
e0

Part Status
Discontinued

Moisture Sensitivity Level (MSL)
4 (72 Hours)

Number of Terminations
48

Terminal Finish
Tin/Lead (Sn/Pb)

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

Subcategory
Other Converters

Technology
CMOS

Terminal Position
QUAD

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
240

Number of Functions
2

Supply Voltage
3.3V

Terminal Pitch
0.5mm

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Pin Count
48

JESD-30 Code
S-PQFP-G48

Qualification Status
Not Qualified

Power Supplies
3.3V

Interface
Parallel

Power Dissipation-Max
274mW

Number of Bits
10

Converter Type
D/A CONVERTER

Supply Type
Analog, Digital

Sampling Rate
130 Msps

Linearity Error-Max (EL)
0.0488%

Input Bit Code
OFFSET BINARY

Number of Converters
2

Analog Output Voltage-Min
-1V

Length
7mm

Height Seated (Max)
1.6mm

Width
7mm

RoHS Status
RoHS Compliant

Lead Free
Contains Lead

Download datasheets and manufacturer documentation for Renesas ISL5729IN.

Datasheets:

intersil-isl5729in-datasheets-8847.pdf

ISL5729IN Overview

The package that contains this software is called LQFP. In order for the device to operate, a supply voltage of 3.3V volts needs to be provided. Part of the Other Converters family, this FPGA part is a programmable gate array. It is designed to maximiBulke space efficiency by containing the FPGA model in Bulk. In total, it has a total of 48 terminations. In my opinion, this FPGA could produce fantastic results if mounted in Surface Mount, provided that its specifications are followed. In order for it to work, it requires a 3.3V power supply. When this module is operated at its maximum operating temperature, it reaches 85°C. A higher operating temperature than -40°C is recommended. A total of 48 pins are included in this device.
