Renesas ISL55143IRZ

Manufacturer No:

ISL55143IRZ

Manufacturer:

Renesas

Package:

Description:

9.5 ns ?s Linear Comparators 2006 50mV mV Surface Mount

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL55143IRZ information

Renesas ISL55143IRZ technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL55143IRZ.

Type
Parameter

Factory Lead Time
5 Weeks

Mount
Surface Mount

Number of Pins
36

Published
2006

JESD-609 Code
e3

Part Status
Active

Moisture Sensitivity Level (MSL)
2 (1 Year)

Number of Terminations
36

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn) - annealed

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

Subcategory
Comparator

Technology
CMOS

Terminal Position
QUAD

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Supply Voltage
12V

Terminal Pitch
0.5mm

Time@Peak Reflow Temperature-Max (s)
30

Pin Count
36

Output Type
3-STATE

Power Supplies
10/18V

Temperature Grade
INDUSTRIAL

Power Dissipation-Max
670mW

Operating Supply Current
-12.5mA

Propagation Delay
15 ns

Quiescent Current
12.5mA

Response Time
9.5 ns

Amplifier Type
COMPARATOR

Current - Input Bias
25nA

Supply Type
Dual

Input Offset Voltage (Vos)
50mV

Average Bias Current-Max (IIB)
0.025?A

Max Dual Supply Voltage
9V

Min Dual Supply Voltage
5V

Bias Current-Max (IIB) @25C
0.025?A

Dual Supply Voltage
7.5V

Height
750?m

Length
6mm

Width
6mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Renesas ISL55143IRZ.

Datasheets:

intersil-isl55143irz-datasheets-9830.pdf

ISL55143IRZ Overview

The comparator has a 3-STATE output.There are 36 terminals on the comparator.The electrical component in this case belongs to the Comparator families.A comparator is capable of completing a variety of demanding tasks when supplied with 12V voltage.As a result, it contains 36 pins.The comparator is equipped with 36 pins.There is a quiescent current of 12.5mA in this comparator.The PCB or other board has a Surface Mount for mounting.In order to run the device, there are only 10/18V power supplies required.An increase in temperature over 85°C is not recommended.Comparator electronics cannot be operated at a temperature lower than -40°C .As a result, 4 channels work together to maintain the quality of the output.A comparator consists of a high-gain COMPARATOR amplifier.

ISL55143IRZ Features

3-STATE output capability
Quiescent Current: 12.5mA
COMPARATOR amplifier

ISL55143IRZ Applications

There are a lot of Intersil (Renesas Electronics America)
ISL55143IRZ linear comparators applications.

Battery management and protection
Current and voltage sensing
Analog front end
Power management
Point of load regulators
DC/DC and AC/DC power supplies
System control and monitoring
Wearable Devices
Mobile Phones and Tablets
Battery-Powered Electronics
