ISL54055IRUZ-T information

Renesas ISL54055IRUZ-T technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL54055IRUZ-T.

  • Type
  • Parameter
  • Contact Plating
  • Tin
  • Mount
  • Surface Mount
  • Number of Pins
  • 6
  • Packaging
  • Tape & Reel
  • Published
  • 2001
  • JESD-609 Code
  • e4
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 6
  • Resistance
  • 360mOhm
  • Terminal Finish
  • Nickel/Palladium/Gold (Ni/Pd/Au)
  • Max Operating Temperature
  • 85°C
  • Min Operating Temperature
  • -40°C
  • HTS Code
  • 8542.39.00.01
  • Subcategory
  • Multiplexer or Switches
  • Technology
  • CMOS
  • Terminal Position
  • DUAL
  • Peak Reflow Temperature (Cel)
  • 260
  • Number of Functions
  • 1
  • Supply Voltage
  • 3V
  • Terminal Pitch
  • 0.4mm
  • Time@Peak Reflow Temperature-Max (s)
  • 40
  • Pin Count
  • 6
  • Polarity
  • Non-Inverting
  • Temperature Grade
  • INDUSTRIAL
  • Number of Channels
  • 1
  • Max Supply Voltage
  • 5.5V
  • Min Supply Voltage
  • 1.8V
  • Analog IC - Other Type
  • SPDT
  • Operating Supply Current
  • 500nA
  • Max Supply Current
  • 500nA
  • Throw Configuration
  • SPST
  • Turn On Delay Time
  • 22 ns
  • Supply Type
  • Single
  • Turn-Off Delay Time
  • 17 ns
  • High Level Output Current
  • 300mA
  • Low Level Output Current
  • 300mA
  • Off-state Isolation-Nom
  • 74 dB
  • Switching
  • BREAK-BEFORE-MAKE
  • Normal Position
  • NC
  • Length
  • 1.2mm
  • Height Seated (Max)
  • 0.55mm
  • Width
  • 1mm
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for Renesas ISL54055IRUZ-T.

Datasheets:

ISL54055IRUZ-T Overview


Advanced packaging method Tape & Reel is used to provide high reliability. There are 6 terminations totally. By its 1 channels, the electronic component provides high-quality output. With a 3V voltage supply, the electrical component should be turned on and run. 6 pins are injected to the electronic part body. This digital multiplexer has 360mOhm internal resistance. Please refer to the datasheets for 6 pins functions. This switch device is a typical Multiplexer or Switches. In a normalsituation, users should not supply the switches with voltage higher than 5.5V. A cost-effective Single supply type analogue multiplexer. The lowest voltage fed to the electronic component should be 1.8V. 500nA current would be enough for this multiplexer to operate. If put voltage greater than 500nA on the device, damage may be caused to the analogue multiplexer. Integrated with SPDT analog IC. The switches should not operate in an environment where the temperature is higher than 85°C.
