Renesas ISL43L841IRZ

Manufacturer No:

ISL43L841IRZ

Manufacturer:

Renesas

Package:

Description:

QUAD Analog Switches BREAK-BEFORE-MAKE 16 Pins 3V

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL43L841IRZ information

Renesas ISL43L841IRZ technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL43L841IRZ.

Type
Parameter

Factory Lead Time
5 Weeks

Contact Plating
Tin

Mount
Surface Mount

Number of Pins
16

Published
2004

JESD-609 Code
e3

Part Status
Active

Moisture Sensitivity Level (MSL)
2 (1 Year)

Number of Terminations
16

Resistance
480mOhm

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

Subcategory
Multiplexer or Switches

Technology
CMOS

Terminal Position
QUAD

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Supply Voltage
3V

Terminal Pitch
0.5mm

Time@Peak Reflow Temperature-Max (s)
30

Pin Count
16

Operating Supply Voltage
3V

Temperature Grade
INDUSTRIAL

Number of Channels
2

Min Supply Voltage
1.65V

Analog IC - Other Type
DIFFERENTIAL MULTIPLEXER

Operating Supply Current
20nA

Max Supply Current
50nA

Throw Configuration
4PST

Propagation Delay
42 ns

Turn On Delay Time
50 ns

Logic Function
Demultiplexer, Multiplexer

Supply Type
Single

Turn-Off Delay Time
27 ns

High Level Output Current
300mA

Low Level Output Current
300mA

Off-state Isolation-Nom
65 dB

On-state Resistance Match-Nom
0.12Ohm

Switching
BREAK-BEFORE-MAKE

Switch-on Time-Max
34ns

Signal Current-Max
0.3A

Height
750?m

Length
3mm

Width
3mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for Renesas ISL43L841IRZ.

Datasheets:

intersil-isl43l841irz-datasheets-1718.pdf

ISL43L841IRZ Overview

Totally, there are 16 terminations. A high-quality output is provided by the electrical component's 2 channels. It is safe to turn on and run the electronic component with a 3V voltage supply. A total of 16 pins are injected into the electrical part body. In this multiplexer, the internal resistance is 480mOhm. For details about the functions of 16 pins, please refer to the datasheets. There is Multiplexer or Switches analog multiplexer like this in the world. It is generally not recommended to supply a voltage higher than 4.5V to the switch device in normal circumstances. The digital multiplexer has a low cost Single supply. 1.65V is the lowest voltage the electrical component should receive. For this digital switch to work, 20nA current would suffice. Putting voltage greater than 50nA on the multiplexer may cause damage. It is integrated with a DIFFERENTIAL MULTIPLEXER analog IC. The electrical part can be operated at 3V voltage levels. An environment with a temperature greater than 85°C should not be used to operate the digital switches.

ISL43L841IRZ Features

2 Channels
20nA Supply Current

ISL43L841IRZ Applications

There are a lot of Intersil (Renesas Electronics America)
ISL43L841IRZ Analog Switches & Multiplexers ICs applications.

Precision data acquisition
Battery-powered systems
Sample-and-hold systems
Communication systems
Data Acquisition Systems
Relay Replacement
Battery Powered Systems
Existing multiplexer applications (both fault-protected and nonfault-protected)
New designs requiring multiplexer functions
Cellular phones
