Renesas ISL43L680IR

Manufacturer No:

ISL43L680IR

Manufacturer:

Renesas

Package:

Description:

QUAD Analog Switches BREAK-BEFORE-MAKE 16 Pins 1.8V

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL43L680IR information

Renesas ISL43L680IR technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL43L680IR.

Type
Parameter

Mount
Surface Mount

Number of Pins
16

Packaging
Bulk

JESD-609 Code
e0

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
16

Resistance
750mOhm

Terminal Finish
Tin/Lead (Sn/Pb)

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

HTS Code
8542.39.00.01

Subcategory
Multiplexer or Switches

Technology
CMOS

Terminal Position
QUAD

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Number of Functions
1

Supply Voltage
1.8V

Terminal Pitch
0.5mm

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Pin Count
16

Qualification Status
Not Qualified

Supply Voltage-Max (Vsup)
3.6V

Power Supplies
1.8/3V

Supply Voltage-Min (Vsup)
1.6V

Number of Channels
8

Operating Supply Current
50nA

Throw Configuration
DPST

Logic Function
Demultiplexer, Multiplexer

Supply Type
Single

Supply Current-Max (Isup)
0.0012mA

On-state Resistance Match-Nom
0.1Ohm

Switching
BREAK-BEFORE-MAKE

Switch-on Time-Max
33ns

Switch-off Time-Max
25ns

Signal Current-Max
0.3A

Length
3mm

Height Seated (Max)
1mm

Width
3mm

RoHS Status
RoHS Compliant

Lead Free
Contains Lead

Download datasheets and manufacturer documentation for Renesas ISL43L680IR.

Datasheets:

intersil-isl43l680ir-datasheets-0151.pdf

ISL43L680IR Overview

The advanced packaging method Bulk provides high reliability. The total number of terminations is 16. As a result of its 8 channels, this electronic component provides high-quality output. An 1.8V voltage supply should allow the electrical part to be turned on and run. A total of 16 pins are injected into the body of the electronic part. The internal resistance of this digital multiplexer is 750mOhm. Datasheets for functions of 16 pins are available. Multiplexer or Switches is a typical switch device. Analogue multiplexer with a Single supply type that is cost-effective. This multiplexer would work with 50nA current. It is not recommended to operate the switches in an environment with a temperature higher than 85°C. To supply the switch device, a voltage of 1.6V must be applied.

ISL43L680IR Features

8 Channels
50nA Supply Current

ISL43L680IR Applications

There are a lot of Intersil (Renesas Electronics America)
ISL43L680IR Analog Switches & Multiplexers ICs applications.

Low-Voltage
Isolation
Medical
Imaging
Ultrasound
Audio and video switching
Automatic test equipment
Precision data acquisition
Battery-powered systems
Sample-and-hold systems
