Renesas ISL43L121IR

Manufacturer No:

ISL43L121IR

Manufacturer:

Renesas

Package:

Description:

DUAL Analog Switches 8 Pins 1.8V

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL43L121IR information

Renesas ISL43L121IR technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL43L121IR.

Type
Parameter

Mount
Surface Mount

Packaging
Bulk

Published
2001

JESD-609 Code
e0

Part Status
Discontinued

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
8

Resistance
250mOhm

Terminal Finish
Tin/Lead (Sn/Pb)

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

Subcategory
Multiplexer or Switches

Technology
CMOS

Terminal Position
DUAL

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
240

Number of Functions
2

Supply Voltage
1.8V

Terminal Pitch
0.65mm

Reach Compliance Code
not_compliant

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Output
SEPARATE OUTPUT

Pin Count
8

JESD-30 Code
S-PDSO-N8

Supply Voltage-Max (Vsup)
3.6V

Power Supplies
1.8/3V

Temperature Grade
INDUSTRIAL

Supply Voltage-Min (Vsup)
1.65V

Number of Channels
2

Analog IC - Other Type
SPDT

Operating Supply Current
30nA

Number of Bits
2

Throw Configuration
SPST

Supply Type
Single

Off-state Isolation-Nom
62 dB

On-state Resistance Match-Nom
0.005Ohm

Switch-on Time-Max
40ns

Switch-off Time-Max
35ns

Normal Position
NC

Length
3mm

Height Seated (Max)
0.8mm

Width
3mm

RoHS Status
RoHS Compliant

Lead Free
Contains Lead

Download datasheets and manufacturer documentation for Renesas ISL43L121IR.

Datasheets:

intersil-isl43l121ir-datasheets-8039.pdf

ISL43L121IR Overview

High reliability is achieved by using advanced packaging method Bulk. A total of 8 terminations have been recorded. The electronic part delivers high-quality output through its 2 channels. Turning on and running the electrical part should be easy with a 1.8V voltage supply. Electronic part bodies are injected with 8 pins. Internally, this switch multiplexer has a resistance of 250mOhm. A analogue multiplexer of this type is a Multiplexer or Switches. Digital switch that provides Single power at a cost-effective price. The switch device would be able to operate with 30nA current. There is an analog IC SPDT integrated with this board. The digital multiplexer has SEPARATE OUTPUT outputs that can be used. Temperatures over 85°C should not be allowed for the multiplexer to operate. Its conductivity is 2-bit. In order to power the analogue multiplexer, it requires an input voltage of 1.65V volts.

ISL43L121IR Features

2 Channels
30nA Supply Current
2-Bit

ISL43L121IR Applications

There are a lot of Intersil (Renesas Electronics America)
ISL43L121IR Analog Switches & Multiplexers ICs applications.

Medical
Imaging
Ultrasound
Audio and video switching
Automatic test equipment
Precision data acquisition
Battery-powered systems
Sample-and-hold systems
Communication systems
Data Acquisition Systems
