Renesas ISL28227FRTBZ-T13

Manufacturer No:

ISL28227FRTBZ-T13

Manufacturer:

Renesas

Package:

Description:

2 Channels 45mA per Channel 1nA 120 dB Instrumentational OP Amps

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL28227FRTBZ-T13 information

Renesas ISL28227FRTBZ-T13 technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL28227FRTBZ-T13.

Type
Parameter

Factory Lead Time
19 Weeks

Mount
Surface Mount

Number of Pins
8

Packaging
Tape & Reel (TR)

Published
2009

JESD-609 Code
e3

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
8

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn) - annealed

Max Operating Temperature
125°C

Min Operating Temperature
-40°C

Subcategory
Operational Amplifier

Technology
BIPOLAR

Terminal Position
DUAL

Peak Reflow Temperature (Cel)
260

Number of Functions
2

Supply Voltage
5V

Terminal Pitch
0.65mm

Time@Peak Reflow Temperature-Max (s)
30

Temperature Grade
AUTOMOTIVE

Number of Channels
2

Max Supply Voltage
40V

Operating Supply Current
2.2mA

Slew Rate
3.6 V/μs

Amplifier Type
OPERATIONAL AMPLIFIER

Common Mode Rejection Ratio
120 dB

Current - Input Bias
1nA

Output Current per Channel
45mA

Input Offset Voltage (Vos)
10μV

Bandwidth
10MHz

Gain Bandwidth Product
10MHz

Neg Supply Voltage-Nom (Vsup)
-5V

Unity Gain BW-Nom
10000 kHz

Voltage Gain
123.52dB

Power Supply Rejection Ratio (PSRR)
117dB

Max Dual Supply Voltage
20V

Min Dual Supply Voltage
2.25V

Input Voltage Noise Density
3nV/sqrt Hz

Input Noise Current Density
0.4pA/sqrt Hz

Length
3mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Renesas ISL28227FRTBZ-T13.

ISL28227FRTBZ-T13 Overview

OPERATIONAL AMPLIFIER-type instrumentation amplifiers are used in this application. The case in which buffer amplifier is delivered is called a Tape & Reel (TR) case. It is estimated that there will be 8 terminations in the next few months. It is important to remember that this op amp should be operated at a voltage of 5V volts. It should be noted that this op amp is a type of Operational Amplifier device. There are 8 pins on this chip. In terms of the input offset voltage, instrumentation amplifier rates at 10μV. An 2.2mA volt supply current is needed for this linear amplifier to operate. There should be no change in the voltage gain. There are 2 channels on the operational amplifiers. In order for op amp to function properly, the temperature should not be lower than -40°C degrees Celsius. Instrumentation amplifier should only be used at temperatures up to 125°C. I would like to point out that this electrical component is capable of working from a voltage below 40V as far as the power supply is concerned. As a general rule, it is advisable to keep the op amp's supply voltage above 4.5V at all times. The dual supply voltage of 20V should be used for the conduct of this electronic component.

ISL28227FRTBZ-T13 Features

supply voltage of 5V
123.52dB voltage gain

ISL28227FRTBZ-T13 Applications

There are a lot of Intersil (Renesas Electronics America)
ISL28227FRTBZ-T13 Instrumentational OP Amps applications.

Addition operation circuits
Subtraction operation circuits
single/dual op amp sum and difference circuits
Integrator circuits
Differentiator circuits
Logarithmic operation circuits
Exponential operation circuits
Multiplication circuits
Division circuits
Precision measurement
