Renesas ISL1572IRZ-T7

Manufacturer No:

ISL1572IRZ-T7

Manufacturer:

Renesas

Package:

VQFN

Description:

2 Channels 750mA per Channel 3μA Instrumentational OP Amps 9V VQFN

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL1572IRZ-T7 information

Renesas ISL1572IRZ-T7 technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL1572IRZ-T7.

Type
Parameter

Factory Lead Time
5 Weeks

Mount
Surface Mount

Package / Case
VQFN

Number of Pins
16

Published
2006

JESD-609 Code
e3

Moisture Sensitivity Level (MSL)
3 (168 Hours)

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn) - annealed

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

Operating Supply Voltage
9V

Number of Channels
2

Max Supply Voltage
13.2V

Min Supply Voltage
4.5V

Operating Supply Current
6mA

Nominal Supply Current
30mA

Max Supply Current
30mA

Slew Rate
1200 V/μs

Current - Input Bias
3μA

Output Current per Channel
750mA

Input Offset Voltage (Vos)
7.5mV

Bandwidth
250MHz

Gain Bandwidth Product
250MHz

Power Supply Rejection Ratio (PSRR)
95dB

Max Dual Supply Voltage
6V

Min Dual Supply Voltage
2.25V

Radiation Hardening
No

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Renesas ISL1572IRZ-T7.

ISL1572IRZ-T7 Overview

There is a VQFN case package that contains the instrumentation amplifiers. 16 pins are located on the operational amplifiers. The input offset voltage is 7.5mV. The buffer amplifier is capable of operating from a supply current of 6mA . It is recommended to keep the voltage gain at 1dB at all times. On the buffer amps, there are 2 channels that can be used. For this linear amplifier to work, the temperature should not be below -40°C. In order to avoid damage to the product, operational amplifiers should only be used at temperatures below 85°C. The operating supply voltage of the buffer op amp is rated at 9V. Under 13.2V is the minimum supply voltage for this electric component. Over 4.5V is a recommended supply voltage for buffer ampsIn order for this electronic part to be conducted successfully, you should use a dual supply voltage of 6V.

ISL1572IRZ-T7 Features

1dB voltage gain

ISL1572IRZ-T7 Applications

There are a lot of Intersil (Renesas Electronics America)
ISL1572IRZ-T7 Instrumentational OP Amps applications.

Exponential operation circuits
Multiplication circuits
Division circuits
Precision measurement
Power control
Information processing
Weak signal detection
Signal amplification
Signal filtering
Signal operation
