Manufacturer No:

IDT74SSTVN16859PAG8

Manufacturer:

Renesas

Package:

TFSOP

Description:

13 Bit 2.5V Specialty Logic IC 0.5mm 2.5V TFSOP

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

IDT74SSTVN16859PAG8 information

Renesas IDT74SSTVN16859PAG8 technical specifications, attributes, parameters and parts with similar specifications to Renesas IDT74SSTVN16859PAG8.

  • Type
  • Parameter
  • Mount
  • Surface Mount
  • Package / Case
  • TFSOP
  • Packaging
  • Tape & Reel (TR)
  • Published
  • 2007
  • JESD-609 Code
  • e3
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 64
  • Terminal Finish
  • Matte Tin (Sn) - annealed
  • Max Operating Temperature
  • 70°C
  • Min Operating Temperature
  • 0°C
  • Additional Feature
  • 220 MHZ FOR PC3200 OPERATION
  • HTS Code
  • 8542.39.00.01
  • Subcategory
  • Other Logic ICs
  • Terminal Position
  • DUAL
  • Terminal Form
  • GULL WING
  • Peak Reflow Temperature (Cel)
  • 260
  • Number of Functions
  • 1
  • Supply Voltage
  • 2.5V
  • Terminal Pitch
  • 0.5mm
  • Time@Peak Reflow Temperature-Max (s)
  • 30
  • Pin Count
  • 64
  • JESD-30 Code
  • R-PDSO-G64
  • Qualification Status
  • Not Qualified
  • Operating Supply Voltage
  • 2.7V
  • Temperature Grade
  • COMMERCIAL
  • Supply Voltage-Min (Vsup)
  • 2.3V
  • Number of Bits
  • 13
  • Family
  • SSTV
  • Logic Function
  • Buffer
  • Output Polarity
  • TRUE
  • Logic IC Type
  • D FLIP-FLOP
  • Trigger Type
  • POSITIVE EDGE
  • Propagation Delay (tpd)
  • 2.7 ns
  • fmax-Min
  • 200 MHz
  • Length
  • 17mm
  • Height Seated (Max)
  • 1.1mm
  • Width
  • 6.1mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for Renesas IDT74SSTVN16859PAG8.

Datasheets:

IDT74SSTVN16859PAG8 Overview


In packaging, Tape & Reel (TR) is used.In the TFSOP package, it can be found.It is essential that the device be able to operate normally by supplying a voltage of 2.5V.Approximately 13 bits of information can be stored in the memory.It adds up to 64 when all component pins are added together.Using 64 terminations prevents signals from reflecting off the transmission line.This is mounted using the Surface Mount method.Other Logic ICs is a subcategory of it.A critical part of its operation is the supply voltage of 2.7V.For convenient use, the power supplies of 2.5V should be maintained.A high level of performance is provided in 220 MHZ FOR PC3200 OPERATION.Optimised for high quality and reliability, this electronic component belongs to the family of SSTV.It is vital that its operating temperature doesn't exceed 70°C.A minimum value of 0°C should be maintained as its operating temperature.It adopts the logic IC type D FLIP-FLOP.

IDT74SSTVN16859PAG8 Features




IDT74SSTVN16859PAG8 Applications


There are a lot of Integrated Device Technology (IDT)
IDT74SSTVN16859PAG8 Specialty Logic ICs applications.


  • Remote controls
  • Wireless network systems
  • Satellite communications networks
  • Ethernet circuitry
  • Wired telephone
  • Cordless telephone
  • Desktop PC
  • Notebook
  • Pocket PC
  • Desktop radio
