Renesas IDT6116LA45TPG

Manufacturer No:

IDT6116LA45TPG

Manufacturer:

Renesas

Package:

PDIP

Description:

5V V Through Hole 24 Pin Memory IC 16 kb kb 95mA mA 8b b

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

IDT6116LA45TPG information

Renesas IDT6116LA45TPG technical specifications, attributes, parameters and parts with similar specifications to Renesas IDT6116LA45TPG.

Type
Parameter

Mount
Through Hole

Package / Case
PDIP

Number of Pins
24

Packaging
Rail/Tube

Published
2008

JESD-609 Code
e3

Number of Terminations
24

ECCN Code
EAR99

Terminal Finish
MATTE TIN

Max Operating Temperature
70°C

Min Operating Temperature
0°C

Subcategory
SRAMs

Technology
CMOS

Terminal Position
DUAL

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Supply Voltage
5V

Terminal Pitch
2.54mm

Time@Peak Reflow Temperature-Max (s)
30

Pin Count
24

Qualification Status
Not Qualified

Operating Supply Voltage
5V

Power Supplies
5V

Temperature Grade
COMMERCIAL

Max Supply Voltage
5.5V

Min Supply Voltage
4.5V

Number of Ports
1

Nominal Supply Current
95mA

Memory Type
RAM, SRAM - Asynchronous

Access Time
45 ns

Organization
2KX8

Output Characteristics
3-STATE

Memory Width
8

Address Bus Width
11b

Density
16 kb

Standby Current-Max
0.00002A

I/O Type
COMMON

Sync/Async
Asynchronous

Word Size
8b

Standby Voltage-Min
2V

Output Enable
YES

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Renesas IDT6116LA45TPG.

Datasheets:

integrateddevicetechnology-idt6116la45tpg-datasheets-6936.pdf

IDT6116LA45TPG Overview

RAM, SRAM - Asynchronous is the type of memory it has. There is a Rail/Tube case available. The PDIP case contains it. The chip has 24 terminations. For a comprehensive working procedure, this part supports as many as 1 functions. In order to operate this memory device, it must be supplied with 5V of power. The memory device is enclosed in a package with an 24-pin connector. There are 24 pins on this memory device, which indicates it has 24 memory locations in it. A voltage of 5V is noted as the operating supply voltage for this memory. In this chip, Through Hole mounting is used, a straightforward, high-efficiency mounting method. In terms of its nominal supply current, this memory component is rated at 95mA. A memory address is accessed through 1 ports on this chip. When it comes to power supplies, this memory chip only requires 5V . I/O port addresses on this device are mapped to memory addresses of COMMON bits. This device must operate at a minimum temperature of 0°C. Temperatures no higher than 70°C degrees Celsius are recommended for operation. It is usually considered a type of SRAMs component. It is recommended that the minimum supply voltage for this part be no less than 4.5V. Ideally, this part should be supplied with a voltage of at least 5.5V.

IDT6116LA45TPG Features

Package / Case: PDIP
24 Pins
Operating Supply Voltage:5V
I/O Type: COMMON

IDT6116LA45TPG Applications

There are a lot of Integrated Device Technology (IDT)
IDT6116LA45TPG Memory applications.

cell phones
eSRAM
mainframes
multimedia computers
networking
personal computers
servers
supercomputers
telecommunications
workstations,
